EN
16
English
Chapter 5 - Other information
Password in Parental Control
- The default password is 1234. You can change it to
a new one.
- The super password is 0423. If you forget your
code, enter the super password to override any
existing codes.
Troubleshooting
Please check the following list before requesting
service.
There is no picture or sound.
Make sure the power cord is properly inserted in the
power outlet.
Make sure the source type is set correctly.
Make sure the antenna is properly connected.
Make sure the volume is not set to minimum or the
sound is not set to mute.
Make sure the headphones are not connected.
The TV may be receiving a signal other than from
TV broadcasting stations.
Picture is not clear.
Make sure the antenna cable is properly connected.
Consider whether your TV signal is being properly
received.
Poor picture quality can occur due to a VHS
camera, camcorder, or other peripheral being
connected at the same time. Switch o󰀨 one of the
other peripherals.
The ‘ghost’ or double image may be caused by
obstruction to the antenna due to high-rise buildings
or hills. Using a highly directional antenna may
improve the picture quality.
The horizontal dotted lines shown on the pictures
may be caused by electrical interference, e.g., hair
dryer, nearby neon lights, etc. Turn o󰀨 or remove
these.
Picture is too dark, too light or tinted.
Check the colour adjustment.
Check the brightness setting.
Check the sharpness function.
Remote control does not work.
Check the batteries of the remote control.
Make sure the remote sensor window on the TV
front is not under strong uorescent lighting.
Try to clean the remote sensor window on the TV
front with a soft cloth.
If the above suggestions do not solve your technical
issue, please refer to the warranty card for service
information.
Operating Conditions
Temperature 5°C – 35°C (41°F – 95°F)
Humidity 20 – 75% (non-condensing)
Storage Conditions
Temperature -15°C – 45°C (5°F – 113°F)
Humidity 10 – 90% (non-condensing)
Radio Information
Bluetooth
®
transmitter frequency range:
2402 – 2480MHz
Bluetooth
®
transmitter power: 6dBm (+/-4dB)
2.4G Wi-Fi transmitter frequency range:
2412 – 2472MHz
2.4G Wi-Fi transmitter power: 14dBm (+4dB / -5dB)
5G Wi-Fi transmitter frequency range:
- Band 1: 5150 – 5250MHz
- Band 2: 5250 – 5350MHz
- Band 3: 5470 – 5725MHz
- Band 4: 5725 – 5850MHz
5G Wi-Fi transmitter power: 14dBm (+4dB / -5dB)
DVB-T/T2/C tuner frequency range: 50.5 858MHz
DVB-S/S2 tuner frequency range: 950 – 2150MHz
* In all EU member states, operation of 5150 –
5350MHz is restricted to indoor use only.
BE BG CZ DK DE EE IE
EL ES FR HR IT CY LV
LT LU HU MT NL AT PL
PT RO SI SK FI SE UK
OSS Notice
This product uses the GPL (Version 2 and 3) and
LGPL (version 2.1) and MPL (version 1.1).
To send inquiries and requests for questions
regarding open source, contact nearest TCL o󰀩ce.
This product uses some software programs which are
distributed under the Independent JPEG Group.
This product uses some software programs which are
distributed under the libpng Project.
This product uses some software programs which are
distributed under the Freetype Project.
This product uses some software programs which are
distributed under the zlib Project.
This product uses some software programs (libxml2,
curl, expat, c-areas) which are distributed under the
MIT.
This product uses CyberLink for C which is distributed
under the Open Source Project.
This product uses opensl, xerces which is distributed
under the Apach License Project.

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the TCL 55C835 and is the answer not in the manual?

TCL 55C835 Specifications

General IconGeneral
Screen shapeFlat
Response time5.7 ms
Display diagonal55 \
Progressive scanYes
Anti-glare screenAlways gives an optimal view, even in direct sunlight.
Display brightness500 cd/m²
Display technologyQLED
Native aspect ratio16:9
Native refresh rate120 Hz
LED backlighting typeMini LED
Display diagonal (metric)139.7 cm
Supported graphics resolutions3840 x 2160
Motion interpolation technologyPPI (Picture Performance Index) 4200
Dynamic contrast ratio marketing nameMega Contrast
Package typeBox
Package depth147 mm
Package width1391 mm
Package height858 mm
Package volume175441.266 cm³
Package weight23120 g
Product colorBlack
Ambient lightingNo
Panel mounting interface300 x 300 mm
Cables includedAC
Remote control typeRC902V1+RC802NU1
AC input voltage100 - 240 V
Power consumption (standby)0.227 W
Power consumption (typical)- W
Programming period8 day(s)
Number of OSD languages29
Firmware upgradeable viaAuto upgrade wizard, Network, USB
Music appsDeezer, Spotify, TIDAL, TuneIn, YouTube Music
Video appsAmazon Prime Video, Apple TV, BBC iPlayer, Disney+, Google TV, HBO, Netflix, Twitch, Vimeo, YouTube
Smart modesDolby Vision Bright, Dolby Vision Dark, Dynamic, Energy saving, IMAX Enhanced, Movie, Sports, Store
Lifestyle appsGoogle Apps
Operating system version11
App distribution platformGoogle Play
Operating system installedGoogle TV
Hybrid Broadcast Broadband TV (HbbTV) version2.0.2
Audio decodersDolby Atmos, Dolby Digital AC4, Dolby TrueHD
RMS rated power20 W
Number of speakers2
Equalizer bands quantity7
Game featuresAuto Low Latency Mode (ALLM), Game Bar, Game Master, Game Master Pro, Variable Refresh Rate (VRR)
Processor cores4
AMD FreeSync typeFreeSync Premium Pro
Audio formats supportedMP3, WMA
Image formats supportedBMP, HEIF, JPG, PNG
Video formats supportedH.264, VP9, WEBM, H.265, WMV, AVI, MPG, TS, MKV, MP4
Video compression formatsAVI, MKV, MP4, MPG, VP9, WEBM, WMV
Picture processing technologyTCL AiPQ 2.0 Engine
High Dynamic Range (HDR) technologyDolby Vision, Dolby Vision IQ, High Dynamic Range 10 (HDR10), High Dynamic Range 10+ (HDR10 Plus), Hybrid Log-Gamma (HLG)
Battery weight15 g
Country of originPoland
Battery technologyAlkaline
Google applicationsGoogle Chat
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6E (802.11ax)
Bluetooth version5.2
Browser supported-
Bluetooth profilesSBC
RF input1
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Consumer Electronics Control (CEC)T-link
Common interface Plus (CI+) version1.4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity0
Tuner typeAnalog & digital
Number of tuners1 tuner(s)
Analog signal format systemNTSC, PAL, SECAM
Digital signal format systemDVB-C, DVB-S2, DVB-T2
Truck type87 cbm
Pallet length1400 mm
Pallet net height1856 mm
Pallet net length800 mm
Pallet net weight246200 g
Quantity per truck280 pc(s)
Quantity per pallet10 pc(s)
Quantity per pallet layer5 pc(s)
Harmonized System (HS) code85287280
Number of layers per pallet2 pc(s)
Number of pallets per truck28 pc(s)
Quantity per master (outer) case1 pc(s)
Master (outer) case GTIN (EAN/UPC)5901292517380
Maximum number of stacking cartons3 pc(s)
Repairability index6.8
Digital Living Network Alliance (DLNA) specificationDMP
Weight and Dimensions IconWeight and Dimensions
Stand depth295 mm
Depth (with stand)280 mm
Height (with stand)790 mm
Weight (with stand)19000 g
Depth (without stand)68 mm
Width (without stand)1222 mm
Height (without stand)712 mm
Weight (without stand)16920 g
