EN
15
English
Using more of your TV
3. Press
to return to the previous menu.
4. For the rst time, activate the screen mirroring
function on your iPhone, iPad, or Mac and
choose the TV’s name you want to connect in the
searching list.
5. If an AirPlay passcode appears on your TV screen,
enter the passcode on your iOS or iPadOS device.
6. To stop mirroring your iOS or iPadOS device, open
Control Center, tap screen mirroring, then tap stop
mirroring.
Notes:
- If your WiFi is turned o, press on the remote
control, select
Settings >
Network and Internet
> Wi-Fi,
and press
OK
to turn it on.
- To disable the feature, select Settings > System
> AirPlay and HomeKit Settings > AirPlay and
press OK to turn it o.
- Apple, AirPlay and HomeKit are trademarks
of Apple Inc., registered in the U.S. and other
countries.
- This Smart TV Pro is compatible with AirPlay
2 and HomeKit. iOS 12.3 or later or macOS
10.14.5 or later is required.
Multi Visual
Allows you to enjoy di󰀨erent programmes with your
family on one TV at the same time.
The multi visual function is enabled by default. To use
the function, make sure your phone is Android OS
and the WiFi on the phone is turned on. Then follow
the steps below to operate.
1. Press
on the remote control, select Settings >
Network and internet > Wi-Fi, and press OK to
turn it on.
2. Press
on the remote control,then select Multi
Visual > Select your desired display mode and
press OK to enter. Press "Start now" to connect.
3. Activate the cast screen function on your phone
and choose the TV’s name you want to connect in
the searching list.
4. For the rst time, depending on di󰀨erent types of
phones, there are two situations:
- An invitation prompt appears, select Accept and
press OK to connect.
- Enter a correct PIN code to connect as per the
PIN message on the phone.
5. Press the option button to choose the audio
source.
6. To exit the multi visual function, press
, then
select OK and press OK to conrm.
Notes:
- This feature is not available in any of the cases
below:
when TV is using Netix or Media Player.
if the video from phone/DTV is scrambled.
when the capacity of required video decoding
exceeds 4K 60Hz.
- When in full screen mode, due to the
compatibility of the third party’s Apps, there might
occur failure to return to the dual views.
- Multiple phones can be used. When in dual view
mode, use ◄/► to move the focus to TV view
and then cast another phone to the TV.
- To disable the function, press
on the remote
control, select Settings > System > Multi visual
settings > Multi visual,and press OK to turn it
o.
- To check all available history list, press
on
the remote control, select Settings > System
> Multi visual settings > Connection list and
press OK to enter.

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the TCL 55C835 and is the answer not in the manual?

TCL 55C835 Specifications

General IconGeneral
Screen shapeFlat
Response time5.7 ms
Display diagonal55 \
Progressive scanYes
Anti-glare screenAlways gives an optimal view, even in direct sunlight.
Display brightness500 cd/m²
Display technologyQLED
Native aspect ratio16:9
Native refresh rate120 Hz
LED backlighting typeMini LED
Display diagonal (metric)139.7 cm
Supported graphics resolutions3840 x 2160
Motion interpolation technologyPPI (Picture Performance Index) 4200
Dynamic contrast ratio marketing nameMega Contrast
Package typeBox
Package depth147 mm
Package width1391 mm
Package height858 mm
Package volume175441.266 cm³
Package weight23120 g
Product colorBlack
Ambient lightingNo
Panel mounting interface300 x 300 mm
Cables includedAC
Remote control typeRC902V1+RC802NU1
AC input voltage100 - 240 V
Power consumption (standby)0.227 W
Power consumption (typical)- W
Programming period8 day(s)
Number of OSD languages29
Firmware upgradeable viaAuto upgrade wizard, Network, USB
Music appsDeezer, Spotify, TIDAL, TuneIn, YouTube Music
Video appsAmazon Prime Video, Apple TV, BBC iPlayer, Disney+, Google TV, HBO, Netflix, Twitch, Vimeo, YouTube
Smart modesDolby Vision Bright, Dolby Vision Dark, Dynamic, Energy saving, IMAX Enhanced, Movie, Sports, Store
Lifestyle appsGoogle Apps
Operating system version11
App distribution platformGoogle Play
Operating system installedGoogle TV
Hybrid Broadcast Broadband TV (HbbTV) version2.0.2
Audio decodersDolby Atmos, Dolby Digital AC4, Dolby TrueHD
RMS rated power20 W
Number of speakers2
Equalizer bands quantity7
Game featuresAuto Low Latency Mode (ALLM), Game Bar, Game Master, Game Master Pro, Variable Refresh Rate (VRR)
Processor cores4
AMD FreeSync typeFreeSync Premium Pro
Audio formats supportedMP3, WMA
Image formats supportedBMP, HEIF, JPG, PNG
Video formats supportedH.264, VP9, WEBM, H.265, WMV, AVI, MPG, TS, MKV, MP4
Video compression formatsAVI, MKV, MP4, MPG, VP9, WEBM, WMV
Picture processing technologyTCL AiPQ 2.0 Engine
High Dynamic Range (HDR) technologyDolby Vision, Dolby Vision IQ, High Dynamic Range 10 (HDR10), High Dynamic Range 10+ (HDR10 Plus), Hybrid Log-Gamma (HLG)
Battery weight15 g
Country of originPoland
Battery technologyAlkaline
Google applicationsGoogle Chat
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6E (802.11ax)
Bluetooth version5.2
Browser supported-
Bluetooth profilesSBC
RF input1
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Consumer Electronics Control (CEC)T-link
Common interface Plus (CI+) version1.4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity0
Tuner typeAnalog & digital
Number of tuners1 tuner(s)
Analog signal format systemNTSC, PAL, SECAM
Digital signal format systemDVB-C, DVB-S2, DVB-T2
Truck type87 cbm
Pallet length1400 mm
Pallet net height1856 mm
Pallet net length800 mm
Pallet net weight246200 g
Quantity per truck280 pc(s)
Quantity per pallet10 pc(s)
Quantity per pallet layer5 pc(s)
Harmonized System (HS) code85287280
Number of layers per pallet2 pc(s)
Number of pallets per truck28 pc(s)
Quantity per master (outer) case1 pc(s)
Master (outer) case GTIN (EAN/UPC)5901292517380
Maximum number of stacking cartons3 pc(s)
Repairability index6.8
Digital Living Network Alliance (DLNA) specificationDMP
Weight and Dimensions IconWeight and Dimensions
Stand depth295 mm
Depth (with stand)280 mm
Height (with stand)790 mm
Weight (with stand)19000 g
Depth (without stand)68 mm
Width (without stand)1222 mm
Height (without stand)712 mm
Weight (without stand)16920 g
