TCL 55C845 User Manual

17
Other Functions
Press
on the remote control
, select
(Settings)
> Channels & Inputs > Channels > PVR > PVR
List
, then select the related record file. Press
OK
to play.
(It is the same if you record a digital radio
program.)
Notes:
- This feature is available only for digital non encrypted
channels.
- Before you connect the USB drive to the TV, make
sure you have backed up the data in the drive
to avoid the loss of your important data due to
unforeseen malfunction.
- The bigger the USB drive free memory for the PVR
function, the bigger the recording length.
- If you want to change channel or signal source
during recording, store the recording data before
changing the channel or source.
- The TV cannot play files normally if the parameters
of the file exceed the limitations of the system, the
file format is not supported, the file is damaged, or
the file cannot be decoded.
- Do not disconnect the USB drive when the system
is reading a file or transmitting data, otherwise the
system or the drive may be damaged.
MagiConnect
MagiConnect, formerly named T-Cast, lets you enjoy
plenty of videos
,
rich of applications, and share great
contents on large screen. It also allows you to turn a
smart device into a sophisticated remote control, provid-
ing more features than your normal TV remote control.
You can then control your TV through your smart
device.
Follow the on-screen instructions to scan the QR code
on the TV screen and download MagiConnect.
Note:
Make sure the smart device and your TV are
in the same home LAN (local area network) or
network segment to use TV remote function.

TCL 55C845 Specifications

General

Control type	Buttons, Wireless
Programming period	8 day(s)
Number of OSD languages	29
Works with Amazon Alexa	Yes
Firmware upgradeable via	Network, USB
Works with Samsung Bixby	No
On Screen Display (OSD) languages	ALB, BUL, CRO, CZE, DAN, DEU, DUT, ENG, ESP, EST, FIN, FRE, GRE, HUN, ITA, LAT, LIT, MAC, NOR, POL, POR, RUM, RUS, SER, SLK, SLV, SWE, TUR, UKR
Color depth	10 bit
Screen shape	Flat
Response time	5.7 ms
Display diagonal	55 \
Display brightness	1500 cd/m²
Display technology	QLED
Native aspect ratio	16:9
Native refresh rate	144 Hz
Peak luminance ratio	65 %
LED backlighting type	Mini LED
Contrast ratio (typical)	-
Display diagonal (metric)	138.8 cm
Motion interpolation technology	PPI (Picture Performance Index) 4300
Dynamic contrast ratio marketing name	Mega Contrast
Cables included	AC
Manual languages	BUL, CZE, DAN, DEU, DUT, ENG, ESP, EST, FIN, FRE, GRE, HUN, ITA, LIT, NOR, POL, POR, RUM, RUS, SER, SLK, SLV, SWE, TUR, UKR
Remote control type	RC833
Pallet width	1400 mm
Pallet height	1862 mm
Pallet length	800 mm
Pallet weight	246200 g
Pallet net weight	241800 g
Quantity per truck	280 pc(s)
Quantity per pallet	10 pc(s)
Master (outer) case width	1391 mm
Quantity per pallet layer	5 pc(s)
Master (outer) case height	858 mm
Master (outer) case length	147 mm
Master (outer) case weight	23120 g
Number of layers per pallet	2 pc(s)
Number of pallets per truck	28 pc(s)
Quantity per master (outer) case	1 pc(s)
Master (outer) case GTIN (EAN/UPC)	5901292519612
Maximum number of stacking cartons	3 pc(s)
Music apps	Spotify
Video apps	Amazon Prime Video, Apple TV, Disney+, Google TV, HBO, Netflix, Twitch, YouTube
Smart modes	IMAX Enhanced
Operating system version	ATV 11.0
App distribution platform	Google Play
Operating system installed	Google TV
Hybrid Broadcast Broadband TV (HbbTV) version	2.0.2
Cord length	1.5 m
User memory	20.9 GB
Battery weight	15 g
Doesn't contain	Lead
Power plug type	Type E
Warranty period	2 year(s)
Country of origin	Poland
Battery technology	Alkaline
Processor frequency	1.4 GHz
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Bluetooth version	5.2
Bluetooth profiles	A2DP, SBC
AC input voltage	220-240 V
AC input frequency	50 Hz
Energy efficiency scale	A to G
Power consumption (standby)	0.5 W
Power consumption (typical)	- W
RF connector type	F, IEC
RF ports quantity	2
HDMI ports quantity	4
USB 2.0 ports quantity	1
Consumer Electronics Control (CEC)	T-link
Common interface Plus (CI+) version	1.4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Sound modes	Movie, Sports, Dynamic, Music, Standard, Game
Audio decoders	DTS, Dolby Atmos, DTS:X, Dolby Digital AC4, Dolby TrueHD
RMS rated power	40 W
Audio output channels	2.1 channels
Equalizer bands quantity	7
Package depth	148 mm
Package width	1392 mm
Package height	861 mm
Package weight	22700 g
Game features	Variable Refresh Rate (VRR)
AMD FreeSync type	FreeSync Premium
Audio formats supported	MP3, WMA
Image formats supported	BMP, HEIF, JPG
Video formats supported	AVI, H.264, H.265, MKV, MP4, MPG, TS, VP9, WEBM, WMV
Subtitle formats supported	ASS, SMI, SRT, SUB
Picture processing technology	TCL AiPQ 3.0 Processor
High Dynamic Range (HDR) technology	Dolby Vision IQ, High Dynamic Range 10 (HDR10), High Dynamic Range 10+ (HDR10 Plus), Hybrid Log-Gamma (HLG)
Processor	MT5889 / 4x CA73
Internal memory	22400 MB
Tuner type	Analog & digital
Number of tuners	1 tuner(s)
Analog signal format system	NTSC, PAL BG, PAL DK, PAL I, PAL L, SECAM B/G, SECAM D/K, SECAM L
Digital signal format system	DVB-C, DVB-S2, DVB-T2
Stand type	Center stand
Product color	Black
Panel mounting interface	300 x 300 mm
Certification	Imax Enhanced, Tüv Rheinland
Sustainability certificates	TUV

Weight and Dimensions

Stand width	295 mm
Depth (with stand)	280 mm
Height (with stand)	794 mm
Weight (with stand)	18400 g
Depth (without stand)	72 mm
Width (without stand)	1225 mm
Height (without stand)	716 mm
Weight (without stand)	16300 g
