TCL 55C845 User Manual

6
Remote Control Functions
Most of your television's functions are available via the menus that appear on the screen. The remote control(s)
supplied with your set can be used to navigate through the menus and to congure all the general settings.
Notes:
1.Figures and illustrations in this operation manual are provided for reference only and may dier from actual product
appearance. 2.The remote control type may be changed without notice, please refer to the remote control attached
with your TV. 3.Certain function may not be available for some models.
Connections and Setup
Circular
D-Pad
OK
To switch the sound o󰀨 and back on.
Standby / quit standby.
Add an entity to Watchlist in Google TV mode, and
display the TV list in DTV mode or future functions.
Press the Assistant button on your remote to talk
to the Google Assistant.
(Available only in Google
TV mode and when the network connection works
normally.)
To display the dashboard menu.
Circular D-Pad
Navigation direction buttons (
Up/Down/Left/Right
).
OK
To conrm an entry or selection.
To return to the previous menu or quit an app.
To access the Google TV homepage.
To access Electronic Program Guide.
(only available
for digital channels.)
To select input source.
/
To control the volume.
P+/P
-
To change channels.
To display and edit the quick settings panel.
To display the quick panel.
To pop up the virtual remote control keyboard when
available.
To open TCL home on screen.
To access Netix.
To access Stan.
To access Prime video.
To access Disney.
To access YouTube.
To access TCL Channel.
Google and Google TV are
trademarks of Google LLC.
Notes:
- Certain function may be accessed from the virtual remote control
keyboard only, please press
button on the remote to display it and
operate accordingly.
- The App buttons may dier depending on the model. The App
button is used for accessing the corresponding App.
-
How to Use the Remote Control
a. Before using the Google Assistant button, you must nish pairing the remote with the TV rst.
b. This Google Assistant function is only available for content search from certain apps.
c. Set languages in the
(Settings) > System > Language
to your local language or o󰀩cial language to en-
hance voice search successfully.

TCL 55C845 Specifications

General

Control type	Buttons, Wireless
Programming period	8 day(s)
Number of OSD languages	29
Works with Amazon Alexa	Yes
Firmware upgradeable via	Network, USB
Works with Samsung Bixby	No
On Screen Display (OSD) languages	ALB, BUL, CRO, CZE, DAN, DEU, DUT, ENG, ESP, EST, FIN, FRE, GRE, HUN, ITA, LAT, LIT, MAC, NOR, POL, POR, RUM, RUS, SER, SLK, SLV, SWE, TUR, UKR
Color depth	10 bit
Screen shape	Flat
Response time	5.7 ms
Display diagonal	55 \
Display brightness	1500 cd/m²
Display technology	QLED
Native aspect ratio	16:9
Native refresh rate	144 Hz
Peak luminance ratio	65 %
LED backlighting type	Mini LED
Contrast ratio (typical)	-
Display diagonal (metric)	138.8 cm
Motion interpolation technology	PPI (Picture Performance Index) 4300
Dynamic contrast ratio marketing name	Mega Contrast
Cables included	AC
Manual languages	BUL, CZE, DAN, DEU, DUT, ENG, ESP, EST, FIN, FRE, GRE, HUN, ITA, LIT, NOR, POL, POR, RUM, RUS, SER, SLK, SLV, SWE, TUR, UKR
Remote control type	RC833
Pallet width	1400 mm
Pallet height	1862 mm
Pallet length	800 mm
Pallet weight	246200 g
Pallet net weight	241800 g
Quantity per truck	280 pc(s)
Quantity per pallet	10 pc(s)
Master (outer) case width	1391 mm
Quantity per pallet layer	5 pc(s)
Master (outer) case height	858 mm
Master (outer) case length	147 mm
Master (outer) case weight	23120 g
Number of layers per pallet	2 pc(s)
Number of pallets per truck	28 pc(s)
Quantity per master (outer) case	1 pc(s)
Master (outer) case GTIN (EAN/UPC)	5901292519612
Maximum number of stacking cartons	3 pc(s)
Music apps	Spotify
Video apps	Amazon Prime Video, Apple TV, Disney+, Google TV, HBO, Netflix, Twitch, YouTube
Smart modes	IMAX Enhanced
Operating system version	ATV 11.0
App distribution platform	Google Play
Operating system installed	Google TV
Hybrid Broadcast Broadband TV (HbbTV) version	2.0.2
Cord length	1.5 m
User memory	20.9 GB
Battery weight	15 g
Doesn't contain	Lead
Power plug type	Type E
Warranty period	2 year(s)
Country of origin	Poland
Battery technology	Alkaline
Processor frequency	1.4 GHz
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Bluetooth version	5.2
Bluetooth profiles	A2DP, SBC
AC input voltage	220-240 V
AC input frequency	50 Hz
Energy efficiency scale	A to G
Power consumption (standby)	0.5 W
Power consumption (typical)	- W
RF connector type	F, IEC
RF ports quantity	2
HDMI ports quantity	4
USB 2.0 ports quantity	1
Consumer Electronics Control (CEC)	T-link
Common interface Plus (CI+) version	1.4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Sound modes	Movie, Sports, Dynamic, Music, Standard, Game
Audio decoders	DTS, Dolby Atmos, DTS:X, Dolby Digital AC4, Dolby TrueHD
RMS rated power	40 W
Audio output channels	2.1 channels
Equalizer bands quantity	7
Package depth	148 mm
Package width	1392 mm
Package height	861 mm
Package weight	22700 g
Game features	Variable Refresh Rate (VRR)
AMD FreeSync type	FreeSync Premium
Audio formats supported	MP3, WMA
Image formats supported	BMP, HEIF, JPG
Video formats supported	AVI, H.264, H.265, MKV, MP4, MPG, TS, VP9, WEBM, WMV
Subtitle formats supported	ASS, SMI, SRT, SUB
Picture processing technology	TCL AiPQ 3.0 Processor
High Dynamic Range (HDR) technology	Dolby Vision IQ, High Dynamic Range 10 (HDR10), High Dynamic Range 10+ (HDR10 Plus), Hybrid Log-Gamma (HLG)
Processor	MT5889 / 4x CA73
Internal memory	22400 MB
Tuner type	Analog & digital
Number of tuners	1 tuner(s)
Analog signal format system	NTSC, PAL BG, PAL DK, PAL I, PAL L, SECAM B/G, SECAM D/K, SECAM L
Digital signal format system	DVB-C, DVB-S2, DVB-T2
Stand type	Center stand
Product color	Black
Panel mounting interface	300 x 300 mm
Certification	Imax Enhanced, Tüv Rheinland
Sustainability certificates	TUV

Weight and Dimensions

Stand width	295 mm
Depth (with stand)	280 mm
Height (with stand)	794 mm
Weight (with stand)	18400 g
Depth (without stand)	72 mm
Width (without stand)	1225 mm
Height (without stand)	716 mm
Weight (without stand)	16300 g
