TCL 55C845 User Manual

9
Connections and Setup
Switching On
1. Connect the power cable FIRST to the television, THEN to a mains
socket. (
Note: For some models, the power lead may be xed to the
television.
)
WARNING:
Your TV set should only be connected to an AC supply.
The TV’s standby light should be turned on. It must not be connected
to a DC supply. If the plug is detached from the cable, do not, under
any circumstances, connect it to a mains socket, as there is a risk of
electric shock.
2. Connect an outside aerial to the
ANTENNA IN
socket at the back of
the TV set.
The aerial socket (75 OHM - VHF / UHF / cable) can be used for
connecting an external aerial or other equipment tted.
3. When powered on, the TV will be turned on directly or be in standby
mode.
If the power indicator lights up, the TV set is in standby mode. Press
the
button on the remote control or on the TV set to turn on the TV.
Initial Setup
The rst time you switch the set on, the Welcome wizard appears, which guides you through the initial setup process.
Follow the on-screen instructions to nish the initial setup process such as selecting the language, pairing your
remote, connecting to the network, and more. During each step, either make a choice or skip the step. If you skip a
step, you can perform the setup later from the Settings menu.
Notes:
- It’s recommended to select
Set up Google TV
and nish its setup to enjoy more features during the initial setup process.
If you have nished basic TV’s setup, you can reaccess Google TV by pressing on the remote control, selecting
(Settings) > Set up Google TV
and pressing
OK
to conrm.
-
When you pair your remote, keep the remote control and TV within 1 meter, and follow the on-screen guide for
pairing. After nishing pairing the remote, you can use the Google Assistant button. If you skip remote pairing, you
will be prompted to pair the remote with the TV again when you use the Google Assistant button for the rst time.
Note: The gures are for representation only,
the location of power socket of the television
might di󰀨er depending on the model.
Switching O󰀨
• To put the TV set into standby mode, press the button on the remote control. The TV set remains powered up,
but with low energy consumption.
• To switch o󰀨 the TV set, unplug the mains socket from the mains outlet.
Note:
In order to save energy and protect environment, certain models are designed with a relay switch. It is a normal
phenomenon if you hear the sound of the relay when you turn on or o the TV set.

TCL 55C845 Specifications

General

Control type	Buttons, Wireless
Programming period	8 day(s)
Number of OSD languages	29
Works with Amazon Alexa	Yes
Firmware upgradeable via	Network, USB
Works with Samsung Bixby	No
On Screen Display (OSD) languages	ALB, BUL, CRO, CZE, DAN, DEU, DUT, ENG, ESP, EST, FIN, FRE, GRE, HUN, ITA, LAT, LIT, MAC, NOR, POL, POR, RUM, RUS, SER, SLK, SLV, SWE, TUR, UKR
Color depth	10 bit
Screen shape	Flat
Response time	5.7 ms
Display diagonal	55 \
Display brightness	1500 cd/m²
Display technology	QLED
Native aspect ratio	16:9
Native refresh rate	144 Hz
Peak luminance ratio	65 %
LED backlighting type	Mini LED
Contrast ratio (typical)	-
Display diagonal (metric)	138.8 cm
Motion interpolation technology	PPI (Picture Performance Index) 4300
Dynamic contrast ratio marketing name	Mega Contrast
Cables included	AC
Manual languages	BUL, CZE, DAN, DEU, DUT, ENG, ESP, EST, FIN, FRE, GRE, HUN, ITA, LIT, NOR, POL, POR, RUM, RUS, SER, SLK, SLV, SWE, TUR, UKR
Remote control type	RC833
Pallet width	1400 mm
Pallet height	1862 mm
Pallet length	800 mm
Pallet weight	246200 g
Pallet net weight	241800 g
Quantity per truck	280 pc(s)
Quantity per pallet	10 pc(s)
Master (outer) case width	1391 mm
Quantity per pallet layer	5 pc(s)
Master (outer) case height	858 mm
Master (outer) case length	147 mm
Master (outer) case weight	23120 g
Number of layers per pallet	2 pc(s)
Number of pallets per truck	28 pc(s)
Quantity per master (outer) case	1 pc(s)
Master (outer) case GTIN (EAN/UPC)	5901292519612
Maximum number of stacking cartons	3 pc(s)
Music apps	Spotify
Video apps	Amazon Prime Video, Apple TV, Disney+, Google TV, HBO, Netflix, Twitch, YouTube
Smart modes	IMAX Enhanced
Operating system version	ATV 11.0
App distribution platform	Google Play
Operating system installed	Google TV
Hybrid Broadcast Broadband TV (HbbTV) version	2.0.2
Cord length	1.5 m
User memory	20.9 GB
Battery weight	15 g
Doesn't contain	Lead
Power plug type	Type E
Warranty period	2 year(s)
Country of origin	Poland
Battery technology	Alkaline
Processor frequency	1.4 GHz
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Bluetooth version	5.2
Bluetooth profiles	A2DP, SBC
AC input voltage	220-240 V
AC input frequency	50 Hz
Energy efficiency scale	A to G
Power consumption (standby)	0.5 W
Power consumption (typical)	- W
RF connector type	F, IEC
RF ports quantity	2
HDMI ports quantity	4
USB 2.0 ports quantity	1
Consumer Electronics Control (CEC)	T-link
Common interface Plus (CI+) version	1.4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Sound modes	Movie, Sports, Dynamic, Music, Standard, Game
Audio decoders	DTS, Dolby Atmos, DTS:X, Dolby Digital AC4, Dolby TrueHD
RMS rated power	40 W
Audio output channels	2.1 channels
Equalizer bands quantity	7
Package depth	148 mm
Package width	1392 mm
Package height	861 mm
Package weight	22700 g
Game features	Variable Refresh Rate (VRR)
AMD FreeSync type	FreeSync Premium
Audio formats supported	MP3, WMA
Image formats supported	BMP, HEIF, JPG
Video formats supported	AVI, H.264, H.265, MKV, MP4, MPG, TS, VP9, WEBM, WMV
Subtitle formats supported	ASS, SMI, SRT, SUB
Picture processing technology	TCL AiPQ 3.0 Processor
High Dynamic Range (HDR) technology	Dolby Vision IQ, High Dynamic Range 10 (HDR10), High Dynamic Range 10+ (HDR10 Plus), Hybrid Log-Gamma (HLG)
Processor	MT5889 / 4x CA73
Internal memory	22400 MB
Tuner type	Analog & digital
Number of tuners	1 tuner(s)
Analog signal format system	NTSC, PAL BG, PAL DK, PAL I, PAL L, SECAM B/G, SECAM D/K, SECAM L
Digital signal format system	DVB-C, DVB-S2, DVB-T2
Stand type	Center stand
Product color	Black
Panel mounting interface	300 x 300 mm
Certification	Imax Enhanced, Tüv Rheinland
Sustainability certificates	TUV

Weight and Dimensions

Stand width	295 mm
Depth (with stand)	280 mm
Height (with stand)	794 mm
Weight (with stand)	18400 g
Depth (without stand)	72 mm
Width (without stand)	1225 mm
Height (without stand)	716 mm
Weight (without stand)	16300 g
