Factory Test & Alignment Specification For MT56 Series (V1.0)
4
Input
&
Output
Audio Out
RCA*2
USB
(Video, audio and picture)
USB2.0*2
MHL
Shares with HDMI 1
PCMCIA
1
SPDIF output
RCA*1
NETWORK
RJ45 Socket
Functions
Internet
WIFI
Others
Serial connector
Multiplexing VGA
IC Details
&
Position
Main program
UF01
(Support online upgrade)
Mboot
UF01
(Support online upgrade)
EEPROM
U702
Note:
The software boot for U702 can be programed by Flash Tool.exe.
Every set has its unique HDCP key which is purchased from suppliers or HDCP
certification authority. Please check HDCP function in the process of production.
Once in a while, the software of main board may be upgraded. Please pay attention to
use the latest software before production.
