TCL 65C825 User Manual

4
Introduction
Sockets and Connections
Note: The location and names of the sockets on the TV may vary according to TV model, and not all sockets
available on all models.
USB 2.0 or USB 3.0 socket (input)
The USB socket(s) can be used to connect a USB 2.0 or USB 3.0
device.
Note: The number of USB sockets on the TV may vary according
to TV model.
LAN
This socket can be used to connect to external modem or network
access equipment.
HDMI, HDMI (SERVICE) or HDMI (eARC/ARC) socket (input)
The HDMI (High-Denition Multimedia Interface) socket can be
used to connect a Blu-ray player, PC with a compatible video
card installed, certain DVD players or a high-denition compatible
digital satellite decoder. This socket provides an uncompressed
digital connection that carries both video and audio data by way
of an integrated mini-plug cable.
ANTENNA/CABLE IN socket (input)
This socket can be used to connect the outside aerial or cable
network.
DIGITAL AUDIO OUT (OPTICAL) socket
This socket can be used to connect a compatible digital audio
receiver.
AV IN adapter socket
This socket can be used to connect a range of equipment,
including video recorders, camcorders, decoders, satellite
receivers, DVD players, or games consoles.
Note: You must connect the attached AV adapter cable with
three color jacks to this socket rst, and then use the yellow jack
for VIDEO connection and the red and white jacks for AUDIO
connection.
Headphone socket (output)
This socket can be used to connect headphones or stereo
earphones.
Note: When the Headphone socket is connected, the speakers
will be muted.
Warning: Excessive sound pressure from earphones and
headphones can cause hearing loss.
DIGITAL
AUDIO OUT
(OPTICAL)
ANTENNA
/CABLE IN
AV IN
adapter
V L R
V L R
V L R
LAN
Router / Modem
USB 2.0
or USB 3.0
HDD
HDMI
or HDMI
(eARC/ARC)
(SERVICE)
or HDMI

TCL 65C825 Specifications

General

Screen shape	Flat
Response time	9 ms
Display diagonal	65 \
Rotating display	No
Anti-glare screen	Yes
Display brightness	1000 cd/m²
Display technology	QLED
Native aspect ratio	16:9
Native refresh rate	120 Hz
LED backlighting type	Mini LED
Supported video modes	2160p
Viewable size diagonal	1640 mm
Viewing angle, vertical	- °
Contrast ratio (typical)	-
Display diagonal (metric)	165.1 cm
Supported graphics resolutions	3840 x 2160
Motion interpolation technology	PPI (Picture Performance Index) 4200
Dynamic contrast ratio marketing name	Mega Contrast
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Energy efficiency scale	A to G
Power consumption (max)	300 W
Power consumption (standby)	0.29 W
Audio decoders	Dolby Atmos, Dolby Digital, Dolby Digital AC4, Dolby TrueHD
RMS rated power	60 W
Number of speakers	2
Package depth	227 mm
Package width	1642 mm
Package height	1085 mm
Package weight	41900 g
Ambient mode	Intelligent Picture
Game features	Auto Low Latency Mode (ALLM), Game Master Pro, Variable Refresh Rate (VRR)
Processor cores	4
Audio formats supported	WMA, MP3
Image formats supported	HEIF, JPG, PNG, BMP
Video formats supported	AVI, WMV, MP4, MPG, TS, MKV, WEBM
Picture processing technology	TCL AiPQ 2.0 Engine
High Dynamic Range (HDR) technology	Dolby Vision IQ, High Dynamic Range 10+ (HDR10 Plus), High Dynamic Range 10 (HDR10), Hybrid Log-Gamma (HLG)
RF connector type	F, IEC
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	1
Consumer Electronics Control (CEC)	T-link
Common interface Plus (CI+) version	1.3
Tuner type	Analog & digital
Number of tuners	1 tuner(s)
Channels quantity	- channels
Analog signal format system	NTSC, PAL, SECAM
Digital signal format system	DVB-C, DVB-S2, DVB-T2
Video apps	Amazon Prime Video, Netflix, YouTube
Smart modes	Game, Movie, Sports
Lifestyle apps	Google Apps
Operating system version	11.0
Operating system installed	Android
Programming period	8 day(s)
Number of OSD languages	39
Firmware upgradeable via	Network, USB
Wi-Fi standards	802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Bluetooth version	5.2
Bluetooth profiles	A2DP, HID
Color name	Brushed Silver Metal
Product color	Silver
Mercury content	0 mg
Panel mounting interface	400 x 400 mm
Cables included	AC
Remote control type	RC802NU1
Truck type	87 cbm
Pallet width	1150 mm
Pallet weight	240000 g
Pallet net height	1220 mm
Pallet net length	1650 mm
Quantity per truck	160 pc(s)
Quantity per pallet	5 pc(s)
Number of pallets per truck	32 pc(s)
Quantity per master (outer) case	1 pc(s)
Master (outer) case GTIN (EAN/UPC)	5901292515690
Maximum number of stacking cartons	3 pc(s)
Doesn't contain	Mercury
Country of origin	Poland
Certification	CE

Weight and Dimensions

Depth (with stand)	290 mm
Width (with stand)	1446 mm
Height (with stand)	904 mm
Weight (with stand)	32000 g
Depth (without stand)	76 mm
Height (without stand)	883 mm
Weight (without stand)	31400 g
