11
2. Select the
Subtitle
option, and press OK to toggle
between on or off.
3. Press to return to the previous menu.
Enabling Subtitle Languages on Digital TV
Channels
1. Press on the remote control, select
(Settings)
> Channels and inputs > Channel > Subtitle >
Digital subtitle language 1st and press OK/Right
to enter.
2. Press Up/Down to select a subtitle language as your
preferred language and press OK to conrm.
3. Press Up/Down to select Digital subtitle language
2nd and press OK/Right to enter.
4. Press Up/Down to select a secondary subtitle
language and press OK to conrm.
5. Press to return to the previous menu.
Selecting a Subtitle Type on Digital TV
Channels
1. Press on the remote control, select
(Settings)
> Channels and inputs > Channel > Subtitle >
Subtitle type and press OK/Right to enter.
2. Press Up/Down to select a subtitle type and press
OK to conrm. You can select Hearing impaired
to display the hearing impaired subtitles with your
selected language.
3. Press to return to the previous menu.
Using Teletext
Selecting Decoding Page Language
1. Press on the remote control, select
(Settings)
> Channels and inputs > Channel > Teletext >
Decoding page language and press OK/Right to
enter.
2. Press Up/Down to select a proper type of language
in which Teletext will display and press OK to
conrm.
3. Press to return to the previous menu.
Digital Teletext Language
On digital TV channels, depending on the broadcaster,
you may be able to enjoy a service with multiple initial
Teletext pages in different languages. This function
allows you to select an available language as primary
language, which relates to different initial Teletext
pages.
1. Press on the remote control, select
(Settings)
> Channels and inputs > Channel > Teletext >
Digital teletext language and press OK/Right to
enter.
Installing Channels
This section describes how to search and store
channels automatically. This may be done in either of
the cases below:
- you are prompted that there are no channels in TV
mode;
- you want to update your channels.
1. In TV mode, press on the remote control, select
(Settings) > Channels and inputs > Channel >
Channel scan and press OK/Right to enter.
2. The TV installs and arranges channels according
to your country or region. Press Up/Down to select
Country/Region, and press OK to enter. Enter
the default password 1234 or your own password
in case you have changed the password in the
(Settings) > System > Lock menu. Press Up/Down
to select your country or region and press OK to
confirm.
3. Press Up/Down to select Automatic search and
press OK to enter.
4. Press Up/Down to select Tuner mode and press
Left/Right to select Cable or Antenna.
5. Press Up/Down to select other options and use
Left/Right to configure.
6. After configuration is completed, press Down to
select Search and press OK to start scanning
channels.
7. The channel search may take a few minutes. After
the automatic search, channels are arranged in
a preset order. If you wish to hide, edit or delete
channels, press on the remote control, select
(Settings) > Channels and inputs > Channel >
Channel organizer and press OK to enter.
Note: If the channel search retrieved only the analog
channels it could be caused by poor broadcasting
and therefore is not covered by manufacturer
warranty. Manufacturers cannot be held
responsible for lack of or poor broadcasting in
some areas.
Using Subtitles
You can enable subtitles for each TV channel. Subtitles
are broadcast via Teletext or DVB-T/DVB-T2/DVB-C
digital broadcasts. With digital broadcasts, you have
the additional option of selecting a preferred subtitle
language.
Note: Some options are available only when Subtitle is
set to on.
Turning On/Off Subtitles
1. Press on the remote control, select
(Settings)
> Channels and inputs > Channel > Subtitle and
press OK/Right to enter.
Chapter 4 Using More of Your TV

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the TCL 65C825 and is the answer not in the manual?

TCL 65C825 Specifications

General IconGeneral
Screen shapeFlat
Response time9 ms
Display diagonal65 \
Rotating displayNo
Anti-glare screenYes
Display brightness1000 cd/m²
Display technologyQLED
Native aspect ratio16:9
Native refresh rate120 Hz
LED backlighting typeMini LED
Supported video modes2160p
Viewable size diagonal1640 mm
Viewing angle, vertical- °
Contrast ratio (typical)-
Display diagonal (metric)165.1 cm
Supported graphics resolutions3840 x 2160
Motion interpolation technologyPPI (Picture Performance Index) 4200
Dynamic contrast ratio marketing nameMega Contrast
AC input voltage220 - 240 V
AC input frequency50 Hz
Energy efficiency scaleA to G
Power consumption (max)300 W
Power consumption (standby)0.29 W
Audio decodersDolby Atmos, Dolby Digital, Dolby Digital AC4, Dolby TrueHD
RMS rated power60 W
Number of speakers2
Package depth227 mm
Package width1642 mm
Package height1085 mm
Package weight41900 g
Ambient modeIntelligent Picture
Game featuresAuto Low Latency Mode (ALLM), Game Master Pro, Variable Refresh Rate (VRR)
Processor cores4
Audio formats supportedWMA, MP3
Image formats supportedHEIF, JPG, PNG, BMP
Video formats supportedAVI, WMV, MP4, MPG, TS, MKV, WEBM
Picture processing technologyTCL AiPQ 2.0 Engine
High Dynamic Range (HDR) technologyDolby Vision IQ, High Dynamic Range 10+ (HDR10 Plus), High Dynamic Range 10 (HDR10), Hybrid Log-Gamma (HLG)
RF connector typeF, IEC
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports1
Consumer Electronics Control (CEC)T-link
Common interface Plus (CI+) version1.3
Tuner typeAnalog & digital
Number of tuners1 tuner(s)
Channels quantity- channels
Analog signal format systemNTSC, PAL, SECAM
Digital signal format systemDVB-C, DVB-S2, DVB-T2
Video appsAmazon Prime Video, Netflix, YouTube
Smart modesGame, Movie, Sports
Lifestyle appsGoogle Apps
Operating system version11.0
Operating system installedAndroid
Programming period8 day(s)
Number of OSD languages39
Firmware upgradeable viaNetwork, USB
Wi-Fi standards802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Bluetooth version5.2
Bluetooth profilesA2DP, HID
Color nameBrushed Silver Metal
Product colorSilver
Mercury content0 mg
Panel mounting interface400 x 400 mm
Cables includedAC
Remote control typeRC802NU1
Truck type87 cbm
Pallet width1150 mm
Pallet weight240000 g
Pallet net height1220 mm
Pallet net length1650 mm
Quantity per truck160 pc(s)
Quantity per pallet5 pc(s)
Number of pallets per truck32 pc(s)
Quantity per master (outer) case1 pc(s)
Master (outer) case GTIN (EAN/UPC)5901292515690
Maximum number of stacking cartons3 pc(s)
Doesn't containMercury
Country of originPoland
CertificationCE
Weight and Dimensions IconWeight and Dimensions
Depth (with stand)290 mm
Width (with stand)1446 mm
Height (with stand)904 mm
Weight (with stand)32000 g
Depth (without stand)76 mm
Height (without stand)883 mm
Weight (without stand)31400 g
