9
Getting Started
Initial Setup
The rst time you switch the set on, the
Welcome wizard
appears, which guides you through the initial setup
process. Follow the on-screen instructions to nish the initial setup process such as selecting the language, pairing
your remote, connecting to the network, and more. During each step, either make a choice or skip the step. If you
skip a step, you can perform the setup later from the settings menu.
Notes:
- It's recommended to select Set up Google TV and finish its setup to enjoy more features during the initial setup
process. If you have finished basic TV's setup, you can reaccess Google TV by pressing on the remote control,
selecting (Settings) > Set up Google TV and pressing OK to confirm.
- When you pair your remote, keep the remote control and TV within 1 meter, and follow the on-screen guide for
pairing. After finishing pairing the remote, you can use the Google Assistant button. If you skip remote pairing, you
will be prompted to pair the remote with the TV again when you use the Google Assistant button for the first time.
TV Buttons
- Power button
If the batteries in your remote control are run down, you can use the button on your TV set.
The model has only one button. It may work just as Power on/Standby button, or as a multi-function controller.
You can turn on the TV by pressing the button at the bottom left of the TV back case.
While the TV is on, press the button to display the multi-function menu. For more information about how to use
the multi-function menu, please refer to the figure below.
CH+ CH- Volume+
Source OKVolume-
Standby
Tips: Short click to change, long click to select.
Press to move the highlight to the next function selection
Press and hold the button for more than 2 seconds to conrm your selection.
Note:
You can follow the on-screen guide to operate. Figures and illustrations are provided for reference only and may
vary depending on the model.
- MIC switch
The MIC switch is located next to the power button. If you want to use the feature of hands-free TV voice control,
turn on the switch.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the TCL 65C825 and is the answer not in the manual?

TCL 65C825 Specifications

General IconGeneral
Screen shapeFlat
Response time9 ms
Display diagonal65 \
Rotating displayNo
Anti-glare screenYes
Display brightness1000 cd/m²
Display technologyQLED
Native aspect ratio16:9
Native refresh rate120 Hz
LED backlighting typeMini LED
Supported video modes2160p
Viewable size diagonal1640 mm
Viewing angle, vertical- °
Contrast ratio (typical)-
Display diagonal (metric)165.1 cm
Supported graphics resolutions3840 x 2160
Motion interpolation technologyPPI (Picture Performance Index) 4200
Dynamic contrast ratio marketing nameMega Contrast
AC input voltage220 - 240 V
AC input frequency50 Hz
Energy efficiency scaleA to G
Power consumption (max)300 W
Power consumption (standby)0.29 W
Audio decodersDolby Atmos, Dolby Digital, Dolby Digital AC4, Dolby TrueHD
RMS rated power60 W
Number of speakers2
Package depth227 mm
Package width1642 mm
Package height1085 mm
Package weight41900 g
Ambient modeIntelligent Picture
Game featuresAuto Low Latency Mode (ALLM), Game Master Pro, Variable Refresh Rate (VRR)
Processor cores4
Audio formats supportedWMA, MP3
Image formats supportedHEIF, JPG, PNG, BMP
Video formats supportedAVI, WMV, MP4, MPG, TS, MKV, WEBM
Picture processing technologyTCL AiPQ 2.0 Engine
High Dynamic Range (HDR) technologyDolby Vision IQ, High Dynamic Range 10+ (HDR10 Plus), High Dynamic Range 10 (HDR10), Hybrid Log-Gamma (HLG)
RF connector typeF, IEC
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports1
Consumer Electronics Control (CEC)T-link
Common interface Plus (CI+) version1.3
Tuner typeAnalog & digital
Number of tuners1 tuner(s)
Channels quantity- channels
Analog signal format systemNTSC, PAL, SECAM
Digital signal format systemDVB-C, DVB-S2, DVB-T2
Video appsAmazon Prime Video, Netflix, YouTube
Smart modesGame, Movie, Sports
Lifestyle appsGoogle Apps
Operating system version11.0
Operating system installedAndroid
Programming period8 day(s)
Number of OSD languages39
Firmware upgradeable viaNetwork, USB
Wi-Fi standards802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Bluetooth version5.2
Bluetooth profilesA2DP, HID
Color nameBrushed Silver Metal
Product colorSilver
Mercury content0 mg
Panel mounting interface400 x 400 mm
Cables includedAC
Remote control typeRC802NU1
Truck type87 cbm
Pallet width1150 mm
Pallet weight240000 g
Pallet net height1220 mm
Pallet net length1650 mm
Quantity per truck160 pc(s)
Quantity per pallet5 pc(s)
Number of pallets per truck32 pc(s)
Quantity per master (outer) case1 pc(s)
Master (outer) case GTIN (EAN/UPC)5901292515690
Maximum number of stacking cartons3 pc(s)
Doesn't containMercury
Country of originPoland
CertificationCE
Weight and Dimensions IconWeight and Dimensions
Depth (with stand)290 mm
Width (with stand)1446 mm
Height (with stand)904 mm
Weight (with stand)32000 g
Depth (without stand)76 mm
Height (without stand)883 mm
Weight (without stand)31400 g
