Page #11 background imageLoading...
Page #11 background image
EN
11
English
Chapter 4 - Using more of your TV
Installing channels
This section describes how to search and store
channels automatically. This may be done in any of
the cases below:
- you have skipped the channel installation step in the
initial setup;
- you are prompted that there are no channels in TV
mode;
- you want to update your channels.
1.
In TV mode, press
on the remote control
and select
Settings > Channels and inputs >
Channel > Channel scan
. Press
OK /
to enter.
2.
The TV installs and arranges channels according
to your country or region. Press
/
to select
Country/Region
, and press
OK /
to enter.
Enter the password you have set in the
Settings
>
System
>
Lock
menu. Press
/
to select your
country or region and press
OK
to conrm.
3.
Press
/
to select
Automatic search
and
press
OK
to enter.
4.
Press
/
to select
Tuner mode
and press
/
to select
Cable
,
Antenna
or
Satellite
.
(Note:
Satellite
option is available only in selected
models.)
5.
Press
/
to select other options to congure.
6.
After conguration is completed, press to select
Search
and press
OK
to start scanning channels.
7.
The channel search may take a few minutes. After
the automatic search, channels are arranged in a
preset order. If you want to edit the channel list,
press
on the remote control, select
Settings
> Channels and inputs > Channel > Edit
Channels
and press
OK
to enter.
Note:
Edit Channels
option is not available
when
Tuner mode
is set to
Antenna
and
Country/Region
is set to United Kingdom.
Common interface
Encrypted digital TV channels can be decoded with a
common interface module and a card provided by a
digital TV service operator.
The common interface module may enable several
digital services, depending on the operator and
services you choose (for example, pay TV). Contact
your digital TV service operator for more information
about services and terms.
Using the common interface module
WARNING: Switch o󰀨 your TV before inserting a
common interface module. Be sure to follow the
instructions described below. Wrong insertion of
a common interface module may damage both the
module and your TV.
1.
Following the directions printed on the common
interface module, gently insert the module into the
common interface slot on the TV.
2.
Push the module in as far as it will go.
3.
Turn on the TV and wait for the common interface
function to be activated. This may take several
minutes.
Note: Do not remove the common interface
module from the slot. Removing the module
will deactivate the digital services.
Accessing common interface services
After inserting and activating the common interface
module, press
on the remote control, select
Settings > Channels and inputs > Channel >
Common interface
and press
OK
to enter.
This menu option is only available if the common
interface module is correctly inserted and activated.
On-screen applications and content are provided by
your digital TV service operator.
Using subtitles
You can enable subtitles for each TV channel.
Subtitles are broadcast via Teletext or DVB-T/DVB-C/
DVB-S/DVB-T2/DVB-S2 digital broadcasts. With
digital broadcasts, you have the additional option of
selecting a preferred subtitle language.
Turning on/o󰀨 subtitles
1.
Press
on the remote control, select
Settings >
Channels and inputs > Channel > Subtitle
and
press
OK /
to enter.
2.
Select the
Subtitle
option, and press
OK
to toggle
between on or o󰀨.
3.
Press to return to the previous menu.
Enabling subtitle languages on digital TV
channels
1.
Press
on the remote control, select
Settings
> Channels and inputs > Channel > Subtitle >
Digital subtitle language 1st
and press
OK
/
to
enter.
2.
Press
/
to select a subtitle language as your
preferred language and press
OK
to conrm.
3.
Press
/
to select
Digital subtitle language
2nd
and press
OK
/
to enter.
4.
Press
/
to select a secondary subtitle
language and press
OK
to conrm.
5.
Press to return to the previous menu.

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the TCL 65C845 and is the answer not in the manual?

TCL 65C845 Specifications

General IconGeneral
Pallet width1650 mm
Pallet height1080 mm
Pallet length1135 mm
Pallet weight210800 g
Pallet net weight208760 g
Quantity per truck192 pc(s)
Master (outer) case width1645 mm
Quantity per pallet layer6 pc(s)
Master (outer) case height995 mm
Master (outer) case length175 mm
Master (outer) case weight31800 g
Number of layers per pallet1 pc(s)
Number of pallets per truck32 pc(s)
Master (outer) case GTIN (EAN/UPC)5901292519605
Maximum number of stacking cartons3 pc(s)
BluetoothYes
Wi-Fi standards802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Bluetooth version5.2
Browser supported-
Bluetooth profilesA2DP, SBC
Color depth10 bit
Screen shapeFlat
Response time5.7 ms
Display diagonal65 \
Display brightness2000 cd/m²
Display technologyQLED
Native aspect ratio16:9
Native refresh rate240 Hz
Peak luminance ratio65 %
LED backlighting typeMini LED
Display diagonal (metric)164 cm
Motion interpolation technologyPPI (Picture Performance Index) 4400
Dynamic contrast ratio marketing nameMega Contrast
AC input voltage220-240 V
AC input frequency50 Hz
Energy efficiency scaleA to G
Power consumption (standby)0.5 W
Power consumption (typical)- W
PC in (D-Sub)No
Headphone outputs1
RF connector typeF, IEC
RF ports quantity2
HDMI ports quantity4
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Consumer Electronics Control (CEC)T-link
Common interface Plus (CI+) version1.4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity0
Package weightWeight of the packaged product in gram.
Game featuresAuto Low Latency Mode (ALLM), Game Master Pro, Gamebar 2.0, HGiG, Variable Refresh Rate (VRR)
AMD FreeSync typeFreeSync Premium
Audio formats supportedMP3, WMA
Image formats supportedBMP, HEIF, JPG
Video formats supportedAVI, H.264, H.265, MKV, MP4, MPG, TS, VP9, WEBM, WMV
Picture processing technologyTCL AiPQ 3.0 Processor
High Dynamic Range (HDR) technologyDolby Vision IQ, High Dynamic Range 10 (HDR10), High Dynamic Range 10+ (HDR10 Plus), Hybrid Log-Gamma (HLG)
Cord length1.5 m
User memory20.9 GB
Battery weight15 g
Doesn't containLead
Power plug typeType E
Warranty period2 year(s)
Country of originPoland
Battery technologyAlkaline
Processor frequency1.4 GHz
Control typeButtons, Wireless
Programming period8 day(s)
Number of OSD languages29
Firmware upgradeable viaNetwork, USB
On Screen Display (OSD) languagesALB, BUL, CRO, CZE, DAN, DEU, DUT, ENG, ESP, EST, FIN, FRE, GRE, HUN, ITA, LAT, LIT, MAC, NOR, POL, POR, RUM, RUS, SER, SLK, SLV, SWE, TUR, UKR
Stand typeCenter stand
Product colorBlack
Panel mounting interface400 x 400 mm
ProcessorMT5889 / 4x CA73
Internal memory22400 MB
Music appsSpotify
Video appsAmazon Prime Video, Apple TV, Disney+, HBO, Netflix, Twitch, YouTube
Operating system versionATV 11.0
App distribution platformGoogle Play
Operating system installedGoogle TV
Hybrid Broadcast Broadband TV (HbbTV) version2.0.2
Cables includedAC
Manual languagesBUL, CZE, DAN, DEU, DUT, ENG, ESP, EST, FIN, FRE, GRE, HUN, ITA, LIT, NOR, POL, POR, RUM, RUS, SER, SLK, SLV, SWE, TUR, UKR
Remote control typeRC833
Tuner typeAnalog & digital
Number of tuners1 tuner(s)
Analog signal format systemNTSC, PAL BG, PAL DK, PAL I, PAL L, SECAM B/G, SECAM D/K, SECAM L
Digital signal format systemDVB-C, DVB-S2, DVB-T2
Audio decodersDTS, Dolby Atmos, DTS:X, Dolby Digital AC4, Dolby TrueHD
RMS rated power60 W
Audio output channels2.1 channels
Equalizer bands quantity7
CertificationImax Enhanced, Tüv Rheinland
Weight and Dimensions IconWeight and Dimensions
Stand width365 mm
Depth (with stand)320 mm
Width (with stand)1446 mm
Height (with stand)865 mm
Weight (with stand)25300 g
Depth (without stand)79 mm
Height (without stand)836 mm
Weight (without stand)22020 g
