Page #12 background imageLoading...
Page #12 background image
EN
12
English
Using more of your TV
Selecting a subtitle type on digital TV
channels
1.
Press
on the remote control, select
Settings
> Channels and inputs > Channel > Subtitle >
Subtitle type
and press
OK /
to enter.
2.
Press
/
to select a subtitle type and press
OK
to conrm. You can select
Hearing impaired
to display the hearing impaired subtitles with your
selected language.
3.
Press to return to the previous menu.
Using Teletext
Selecting decoding page language
1.
Press
on the remote control, select
Settings
> Channels and inputs > Channel > Teletext >
Decoding page language
and press
OK /
to
enter.
2.
Press
/
to select a proper type of language
in which Teletext will display and press
OK
to
conrm.
3.
Press to return to the previous menu.
Digital Teletext language
On digital TV channels, depending on the
broadcaster, you may be able to enjoy a service with
multiple initial Teletext pages in di󰀨erent languages.
This function allows you to select an available
language as primary language, which relates to
di󰀨erent initial Teletext pages.
1.
Press
on the remote control, select
Settings
> Channels and inputs > Channel > Teletext >
Digital teletext language
and press
OK /
to
enter.
2.
Press
/
to select a language and press
OK
to conrm.
3.
Press to return to the previous menu.
External devices control (CEC)
Use this function to search for CEC devices connected
to the HDMI sockets in your TV and enable one-touch
play and one-touch standby between CEC devices.
Enabling or disabling CEC
1.
Press
on the remote control, select
Settings
> Channels and inputs > Inputs > External
devices control (CEC)
and press
OK /
to enter.
2.
Select the
HDMI Control
option, and press
OK
to
toggle between on or o󰀨.
3.
Press to return to the previous menu.
Using Auto power on
Enables the TV to automatically power on when you
power on a CEC device (e.g. DVD) with the device’s
remote. Press
OK
to turn it on to enable this function.
Using Auto standby
Enables all CEC devices to automatically go to the
standby mode when you turn o󰀨 the TV with the TV
remote. Press
OK
to turn it on to enable this function.
Note: The CEC functions depend on the devices
connected and it is possible that some
devices may not interoperate correctly when
connected to this TV. The user manual or the
manufacturer of the problematic devices should
be consulted for further information.
HbbTV
HbbTV (Hybrid broadcast broadband TV) is a service
o󰀨ered by certain broadcasters and available only on
some digital TV channels. HbbTV delivers interactive
television over broadband Internet. These interactive
features are added to and enrich the normal digital
programmes, and include services such as digital
teletext, electronic programme guide, games, voting,
specic information related to the current programme,
interactive advertising, information magazines, catch-
up TV, etc.
To use HbbTV please ensure your TV is connected to
Internet and HbbTV is switched on.
Notes:
-
HbbTV services are broadcast- or country-
dependent and may be unavailable in your area.
-
You cannot download les to your TV with
HbbTV function.
-
Application provider or broadcasting related
conditions may cause an HbbTV application to
be unavailable momentarily.
-
To access HbbTV applications you must connect
your TV to the Internet via a broadband link.
HbbTV applications may not work correctly in
case of network related issues.
HbbTV access
1.
Press
on the remote control, select
Settings
> System > HbbTV settings
and press
OK /
Select the
HbbTV
option, and press
OK
to turn it
on.
2.
When you tune to a digital TV channel that o󰀨ers
HbbTV, this will be signalled to you by an on-
screen indication (generally a red button, but
other colour buttons may also be used). Press
the indicated colour button to open the interactive
pages.

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the TCL 65C845 and is the answer not in the manual?

TCL 65C845 Specifications

General IconGeneral
Pallet width1650 mm
Pallet height1080 mm
Pallet length1135 mm
Pallet weight210800 g
Pallet net weight208760 g
Quantity per truck192 pc(s)
Master (outer) case width1645 mm
Quantity per pallet layer6 pc(s)
Master (outer) case height995 mm
Master (outer) case length175 mm
Master (outer) case weight31800 g
Number of layers per pallet1 pc(s)
Number of pallets per truck32 pc(s)
Master (outer) case GTIN (EAN/UPC)5901292519605
Maximum number of stacking cartons3 pc(s)
BluetoothYes
Wi-Fi standards802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Bluetooth version5.2
Browser supported-
Bluetooth profilesA2DP, SBC
Color depth10 bit
Screen shapeFlat
Response time5.7 ms
Display diagonal65 \
Display brightness2000 cd/m²
Display technologyQLED
Native aspect ratio16:9
Native refresh rate240 Hz
Peak luminance ratio65 %
LED backlighting typeMini LED
Display diagonal (metric)164 cm
Motion interpolation technologyPPI (Picture Performance Index) 4400
Dynamic contrast ratio marketing nameMega Contrast
AC input voltage220-240 V
AC input frequency50 Hz
Energy efficiency scaleA to G
Power consumption (standby)0.5 W
Power consumption (typical)- W
PC in (D-Sub)No
Headphone outputs1
RF connector typeF, IEC
RF ports quantity2
HDMI ports quantity4
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Consumer Electronics Control (CEC)T-link
Common interface Plus (CI+) version1.4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity0
Package weightWeight of the packaged product in gram.
Game featuresAuto Low Latency Mode (ALLM), Game Master Pro, Gamebar 2.0, HGiG, Variable Refresh Rate (VRR)
AMD FreeSync typeFreeSync Premium
Audio formats supportedMP3, WMA
Image formats supportedBMP, HEIF, JPG
Video formats supportedAVI, H.264, H.265, MKV, MP4, MPG, TS, VP9, WEBM, WMV
Picture processing technologyTCL AiPQ 3.0 Processor
High Dynamic Range (HDR) technologyDolby Vision IQ, High Dynamic Range 10 (HDR10), High Dynamic Range 10+ (HDR10 Plus), Hybrid Log-Gamma (HLG)
Cord length1.5 m
User memory20.9 GB
Battery weight15 g
Doesn't containLead
Power plug typeType E
Warranty period2 year(s)
Country of originPoland
Battery technologyAlkaline
Processor frequency1.4 GHz
Control typeButtons, Wireless
Programming period8 day(s)
Number of OSD languages29
Firmware upgradeable viaNetwork, USB
On Screen Display (OSD) languagesALB, BUL, CRO, CZE, DAN, DEU, DUT, ENG, ESP, EST, FIN, FRE, GRE, HUN, ITA, LAT, LIT, MAC, NOR, POL, POR, RUM, RUS, SER, SLK, SLV, SWE, TUR, UKR
Stand typeCenter stand
Product colorBlack
Panel mounting interface400 x 400 mm
ProcessorMT5889 / 4x CA73
Internal memory22400 MB
Music appsSpotify
Video appsAmazon Prime Video, Apple TV, Disney+, HBO, Netflix, Twitch, YouTube
Operating system versionATV 11.0
App distribution platformGoogle Play
Operating system installedGoogle TV
Hybrid Broadcast Broadband TV (HbbTV) version2.0.2
Cables includedAC
Manual languagesBUL, CZE, DAN, DEU, DUT, ENG, ESP, EST, FIN, FRE, GRE, HUN, ITA, LIT, NOR, POL, POR, RUM, RUS, SER, SLK, SLV, SWE, TUR, UKR
Remote control typeRC833
Tuner typeAnalog & digital
Number of tuners1 tuner(s)
Analog signal format systemNTSC, PAL BG, PAL DK, PAL I, PAL L, SECAM B/G, SECAM D/K, SECAM L
Digital signal format systemDVB-C, DVB-S2, DVB-T2
Audio decodersDTS, Dolby Atmos, DTS:X, Dolby Digital AC4, Dolby TrueHD
RMS rated power60 W
Audio output channels2.1 channels
Equalizer bands quantity7
CertificationImax Enhanced, Tüv Rheinland
Weight and Dimensions IconWeight and Dimensions
Stand width365 mm
Depth (with stand)320 mm
Width (with stand)1446 mm
Height (with stand)865 mm
Weight (with stand)25300 g
Depth (without stand)79 mm
Height (without stand)836 mm
Weight (without stand)22020 g
