 Main camera function failure
Check whether the connection
between main camera and Main
camera connector is good
N
Y
N
Check whether main camera is
normal
Y
Check whether Main camer a
connector is normal
N
Reassemble main camera
Replace main camera
Reweld or replace Main
camera connector
Y
Replace PCBA
Main camera function
failure
Y
