TCL Alto 5 User Manual

16
Mount your Sound Bar main unit on the wall
You can choose to place your Sound Bar main unit below
the center of your TV or mount it on the wall.
A B
1
Place the supplied wall mount template on the wall.
Make sure the wall mount template is at least 2 inches
(5cm) below the center of the TV.
2
Use a level to make sure the Sound Bar is positioned
accurately.
3
Use the tape to stick the wall mount template rmly on
the wall.
4
Mark on the wall using each marking on the template on
the template through the mounting holes (Fig.1).
5
Take away the wall mount template.
6
Drill a screw hole at each marking on the wall.
7
Insert the supplied wall anchors into 4 screw holes on
the wall (Fig. 2).
8
Insert the supplied wall bracket screws into the wall
anchors. Leave 0.16 inch (4mm) between the screw
heads and the wall (Fig. 2).
