TCL Alto 5 User Manual

17
9
Fix and tighten the wall bracket screws on the wall.
Stick the silicone pads on the wall mount brackets when
necessary to adjust the direction of the Sound Bar main
unit (Fig. 2).
10
Replace the screws at the back of the Sound Bar main
unit with the supplied wall mounting screws (Fig. 3 and
4).
11
Hang the Sound Bar main unit on the screws.
Remove
the screws
Install the wall
mounting screws
Fig.1 Fig.3
Fig.4
Fig.2
Wall template
Silicone pad
735 mm / 28.94”
735 mm/28.94”
Fig. 1
Wall template
Silicone pad
Remove the screws
Install the wall
mounting screws
Fig. 3
Fig. 2
Fig. 4

TCL Alto 5 Specifications

General

Brand	TCL
Model	Alto 5
Category	Speaker System
Language	English
