TCL CWH09TBAI User Manual

Air Conditioner Service Manual
12
PAERTS LIST
Indoor Unit-CWH09TBAI
No.
Part No.
Part Name
Q’ty
Remark
1
210838031
Installation Plate
1
2
210755108W
Base
1
3
210701883C
Vertical Vane Assembly
2
4
210701905B
Vertical Vane Connector
1
5
210737659H
Vane
1
6
210737655
Cross Fan
1
7
1070100010
Bearing Mount
1
8
211237323B
Evaporator
1
9
210755110B
Face Frame
1
10
210701846AF
Screw Cover
1
11
210701863F
Air Filter
2
12
210738739A
Display PCB Box
1
13
210901127S
Display PCB
1
14
210755078C
Front Panel
1
210755045Q
Glass Panel
1
15
1170120044B
Power Supply Cord
1
16
210737654H
Electrical Box Cover
1
17
210736832
Cable Clamp
1
18
210900478A
Terminal
1
19
210901224
Transformer
1
20
210901714CE
Main PCB
1
21
210900333
Indoor Sensor Assembly
1
22
210736831
Electrical Box
1
23
1170030067G
Indoor Motor
1
24
210737653
Indoor Motor Cover
1
25
210701903B
Right Vertical Vane Supporter
1
26
210701902
Step Motor connector
1
27
210900129
Step Motor
1
28
210701906
Step Motor Supporter
1
29
210737091
Drainage Hose
1
30
1170020011
Vane Motor
1
31
210736813C
In And Out Pipe Fixer
1
32
210902178F
Remote Controller
1
Not shown in Explosion view
33
211386678GC
Indoor Carton
1
34
211386186
Left Foaming
1
35
211386187
Right Foaming
1

TCL CWH09TBAI Specifications

General

Brand	TCL
Model	CWH09TBAI
Category	Air Conditioner
Language	English
