TCL CWH09TBAI User Manual

Air Conditioner Service Manual
15
OUTDOOR UNIT-CWH09TBAO
No.
Part No.
Part Name
Q’ty
Remark
1
1071990039
Grille
1
2
210800539
Top cover
1
3
211239732
Condenser
1
4
1080050004
Outdoor motor supporter
1
5
1170040162AB
Outdoor motor
1
6
1070030060
Propeller fan
1
7
1080050001
Left grille supporter
1
8
210800537
Front plate
1
9
210754635
Fan guard
1
10
211239580
Compressor and accessories
1
11
1120110016J
4-way valve
1
12
211232688B
4-way valve assembly
1
13
210800545
Base
1
14
210800541
Right plate
1
15
1120120021
Two-way valve
1
16
1080050003
Valve supporter
1
17
211206766
Three-way valve
1
18
1070350971
Electronic Box Cover
1
19
1070040003
Cable clamp
1
20
1170200061
Terminal
1
21
210901772AD
Outdoor PCB Assembly
1
22
210901769
Inductor
1
23
211242474
Capillary assembly
1
24
1080050119
Partition plate
1
25
1170230007E
Pipe Temp. sensor and
outdoor Temp. sensor
1
Not shown in explosion view
26
1170230006C
Discharge Temp. sensor
1
27
211369052
Base carton
1
28
211311098AZL
Cabinet carton
1
29
211311099
Base foaming
1
30
211311100
Cover foaming
1
