TCL LCD-27VSE User Manual

27’’ LCD TV Color Monitor TCL LCD-27VSE
59
L2 071T 56U601 MA 0805 600 OHM
L1 071T 56U601 MA 0805 600 OHM
S4 077T 604 2 TO CHIP TACT SW TS-9-TMG-533
S3 077T 604 2 TO CHIP TACT SW TS-9-TMG-533
S2 077T 604 2 TO CHIP TACT SW TS-9-TMG-533
S1 077T 604 2 TO CHIP TACT SW TS-9-TMG-533
S5 077T 604 2 TO CHIP TACT SW TS-9-TMG-533
S6 077T 604 2 TO CHIP TACT SW TS-9-TMG-533
S7 077T 604 2 TO CHIP TACT SW TS-9-TMG-533
D1 093T 6433P BAV99
715T1623 1 KEY BOARD PCB
Q1 057T 417 6 PMBS3906/PHILIPS-SMT
R43 061V0603101 CHIPR 100 OHM+-5% 1/10W
R45 061V0603103 CHIPR 10K OHM+-5% 1/10W
R44 061V1206301 CHIP 300 OHM 5% 1/8W
R46 061V1206331 CHIP 330 OHM 5% 1/8W
C43 065T0603102 32 GP CHIP 1000PF 50V X7R
C42 065T0603104 32 CHIP 0.1UF 50V X7R
C41 065T0603104 32 CHIP 0.1UF 50V X7R
C39 065T0603104 32 CHIP 0.1UF 50V X7R
C40 065T0805475 A5 CHIP 4.7UF 10V X5R
FB8 071T 59B601 EA CHIP BEAD 600OHM 0603 TB1608
FB7 071T 59B601 EA CHIP BEAD 600OHM 0603 TB1608
FB6 071T 59B601 EA CHIP BEAD 600OHM 0603 TB1608
715T1836 A 3 IR BOARD PCB
C3 065T0603103 32 CHIP 0.01UF 50V X7R
C2 065T0603103 32 CHIP 0.01UF 50V X7R
C1 065T0603103 32 CHIP 0.01UF 50V X7R
FB2 071T 56U601 BEAD 600 OHM
FB1 071T 56U601 BEAD 600 OHM
FB3 071T 56U601 BEAD 600 OHM
715T1290 1 5 PCB FOR HJPF PCB

TCL LCD-27VSE Specifications

General

Brand	TCL
Model	LCD-27VSE
Category	LCD TV
Language	English
