TCL Air Conditioner Service Manual
Protection display code list:
Protection type LED CODE DIGITAL LED CODE
higher or lower voltage RUN-winking,TIMER-1 time/8s P1
Over current RUN- winking,TIMER-2 times /8s P2
Discharge temperature RUN- winking,TIMER-4 times /8s P4
Over cooling in cooling mode RUN-light,TIMER-5 times /8s P5
Over heating in cooling mode RUN- light,TIMER-6 times /8s P6
Over heating in heating mode RUN- light,TIMER-7 times /8s
P7
Outdoor temperature too high or low RUN- light,TIMER-8 times /8s P8
Drive protection(Overload)
RUN- winking,TIMER-9 times/8s P9
Module self protection RUN- winking,TIMER-10 times/8s P0
z Outdoor failure display
There is a LED on outdoor power board, when compressor is running; it is normally light;
when no feedback of signal to power board from compressor, it will wink by lighting 1s and
going out 1s. If failures happened, it will light 0.5s, go out 0.5s, winking several times and go
out 3s for a cycle to indicate failures. The failure list is the follow:
Wink time Failure
1
IPM protection
2
higher or lower voltage
3
Over current
4
Discharge temperature too high
5
Outdoor coil temperature too high
6
Drive abnormity
7
Communication abnormity with indoor unit
8
Compressor over heat（switch on top of compressor）
9 Outdoor air temperature sensor failure
10 Outdoor coil temperature sensor failure
11 Outdoor discharge pipe temperature sensor failure
12 Voltage sensor failure
13 Current sensor failure
14 IPM abnormity
15 Outdoor communication abnormity
16 DC fan motor no feedback
17 defrosting
10
