TCL Air Conditioner Service Manual
14
PART LIST
Indoor unit
Model: TAC-12CHSA/GI
No. Part No. Part Name Q’ty Remark
1 1080030008 Installation plate 1
2 1210320107 Base 1
3 1070020016 Cross fan 1
4 1070100010 Bearing Mount 1
5 1110050068 Evaporator 1
6 1070320103 Water Drainage Assembly 1
7 1070320105 Vertical Vane Assembly 2
8 1070320121 Face frame 1
9 1070320112 Screw cover 2
10 1090251109 Display PCB 1
11 1070320115 Display PCB box 1
12 1070320109 Air filter 2
13 1070321113 panel 1
14 1070321107 Ornament strip 1
15 1170120045 Power supply cord 1
16 1070320104 vane 1
17 1070110008 Drainage hose 1
18 1070040004 Cable clamp 1
19 1170200042 Terminal 1
20 1070250109 Terminal fixing board 1
21 1170020011 Vane motor 1
22 1090320163 Main PCB 1
23 1073030201 Sensor holder 1
24 1070320113 Electrical box 1
25 1070320111 Indoor motor cover 1
26 1170030067 Indoor motor 1
27 1170240001 transformer 1
28 1170230001 Temperature sensor assembly 1
29 1090010071 Remote controller 1
30 1073030303 Remote controller supporter 1
31 1190060008 Left foaming 1
32 1190060009 Right foaming 1
Not shown in explosion
view
To Next Page
