TCL TAC-09CHSA/GI

TCL Air Conditioner Service Manual
16
PART LIST
Outdoor unit
Model: TAC-09CHSA/GI
No. Part No. Part Name Q’ty Remark
1 1080050026 Grille 1
2 1190070021 Top cover 1
3 1110060083 Condenser 1
4 1080050004 Outdoor motor supporter 1
5 1170040058 Outdoor motor 1
6 1070030016 Propeller fan 1
7 1080050001 Left grille supporter 2
8 1080050007 Left grille 1
9 1080050009 Front plate 2
10 1080320112 Fan guard 1
11 1100060052 Compressor and accessories 1
12 1140020004 Sound arrester 2 420mm*240mm*12mm
13 1120110016 4-way valve 1
14 1120250427 Three-way valve connecting pipe 1
15 1120250425 Suction pipe 1
16 1120250426 Discharge pipe 1
17 1120250428 Condenser connecting pipe 1
18 1120250615 Capillary assembly 1
19 1140020011 Sound arrester 1 750*350*8
20 1080050002 Right plate 1
21 1080050003 Valve supporter 1
22 1120120021 Two-way valve 1
23 1210250121 Base 1
24 1120130036 Three-way valve 1
25 1170190003 Inductor 1
26 1170230007 Pipe Temp. sensor and outdoor Temp. sensor 1
27 1080320001 Clapboard 1
28 1170230006 Discharge Temp. sensor 1
29 1070320202 Sensor holder(φ10) 1
30 1070040007 Cable clamp(φ10) 1
31 1170200061 Terminal 1
32 1170100010 Fan motor capacitor 1
33 1070320207 Electrical box 1
34 1090321110 Power source board 1
35 1090321112 Invert board 1
36 1090320003 PFC board 1
37 1170330001 Radiator 1
