TCL Air Conditioner Service Manual
64
step4：Disassemble the Axis Fan Blade
A
Unscrew the fan
blade nut, and take
the blade out.
step5：Disassemble the electric box
Unfix screw btw
Electric Box and
motor supporter etc.
loosen the wiring
clamp, then you can
take the control box
out.
step6：take out the noise cotton
