TCL Air Conditioner Service Manual

10

7K, 9K, 12K, 18K，24K

Top vi e w

A010422

1 TransformerIN

2 ODUACpoweroutput

3 Fuse

4 ODUACpowerinput

5 ACmotordriver

6

IDU/ODUwiring

connection‐Nconnector

7

Powersupply‐N

connector

8

Left‐Rightswing

connector

9

Up‐Downswing

connector

10 ACMotorfeedback

11 Emergencybutton

12

Temperaturesensor

connector

13 WIFIconnection

14 Display

15 TransformerOUT

16 Anionconnrctor
