TCL AIR-CON SERVICE MANUL
TAC---42C(H)F INDOOR UNIT EXPLOSION VIEW
back view back view
1214090210 OPERATION PANEL
1094090202 OPERATION
PCB(for heating&cooling)
1094090404 OPERATION PCB
(for only cooling)
1074090121 INDOOR GRILLE
1074090122 AIR FILLTER
1074090121 GRILLE
1214090116 MIDLLE PANEL
1170010004 SWING MOTOR
1074090108 HORIZONTAL VANE
1074090110
VERTICAL VANE
1074090103 BASE
