Schematic diagram for welding of pipelines in compressor compartment:

Intubation of process

tube (copper and copper)

Connection between the

outlet of the dry filter and

the capillary tube (copper

and copper)

Connection between the

dew removable tube and

the dry filter (steel and

copper)

Connection between the outlet of the

return-air duct and the return-air

transition duct (copper and copper)

Connection between the

outlet of the evaporation

coil and the inlet of the

condenser (steel and steel)

Connection between the

compressor exhaust and

the inlet of the

evaporation coil (copper

and steel)

Welding position

of process tube
