Evaporator outlet, connection
pipe for air return pipe
The fixed position of Defroster sensor,
sensor is fixed on the outside of the
baffle
Water tray is coated with
aluminum foil
Reservoir
The fixed position of the evaporator
foam is about the position of Row 5.6
at the downwards of the left and
right, respectively.
Schematic diagram of freezer chamber
Evaporator inlet, connection pipe for
capillary tubes
Heating tube of defroster
The foam block is wrapped with
aluminum foil
