7. HYDRAULIC SYSTEM
- 129 -
⑭ Secure the oil seal with a snap ring and remove the oil seal guide.
Fig. 7.48
Fig. 7.49
Cross section of
“C” lock ring
Side at which corner is
chamfered.
(Front cover)
Oil seal
ø4
[0.16]
ø17
[0.67]
R2
[0.08]
20°
R5
[0.2]
2 [0.08]
62 [2.44]
71 [2.8]
92 [3.622]
23.0
0
-0.05
22.05
+0.05
-0
100 [3.9]
115 [4.5]
Oil seal snapOil seal guide
R2
[0.08]
R2
[0.08]
ø4
[0.16]
23.1
-0.05
0
[0.91 ]
-0.002
0
35.5 [1.398 ]
+0.5
0
+0.02
0
[0.906 ]
0
-0.002
[0.868 ]
+0.002
-0
Fig. 7.50
