TCM FB18-7 - LOAD HANDLING SYSTEM

8. LOAD HANDLING SYSTEM
- 133 -
A: 43 mm
[1.69 in.]
B: 102.5 mm
[4.04 in.]
C: 134.5 mm
[5.30 in.]
D:
72 mm
[2.83 in.]
A: 45 mm
[1.77 in.]
B: 119.5 mm
[4.71 in.]
C: 159.5 mm
[6.28 in.]
D:
76 mm
[2.99 in.]
A: 44 mm
[1.73 in.]
B: 102.5 mm
[4.04 in.]
C: 134.5 mm
[5.30 in.]
A: 48 mm
[1.89 in.]
B: 119.5 mm
[4.71 in.]
C: 161.5 mm
[6.36 in.]
A: 60 mm
[2.36 in.]
B: 124 mm
[4.88 in.]
C: 170 mm
[6.69 in.]
←
←
A: 54 mm
[2.13 in.]
B: 124 mm
[4.88 in.]
C: 170 mm
[6.69 in.]
D:
89 mm
[3.50 in.]
8. LOAD HANDLING SYSTEM
Model FB10-7 FB15-7 FB20-7 FB25-7 FB30-7
FB35-7S
Item FB18-7
FB25-7LB FB25-7V FB30-7V
Name VM-81E VM-81N VM-39F FM-77X
Type Roller type 2-step telescopic mast with free lift
Max. standard lifting height 3000 mm [118.1 in.]
Fork lifting system Hydraulic
Mast tilting system Hydraulic
Lift chain Leaf chain BL623 Leaf chain BL634 Leaf chain BL823 Leaf chain BL834
Mast cross section
Outer mast
Inner mast
A
C
B
D
A
C
B
