TCNet Boiler Controller
User and Service Manual
20
Boiler Setup
Max. Power kW
25
The maximum power of the
boiler
Min. Power kW
5
The minimum power of the
boiler
Feed rate gr/min
380
The pellet feed amount for a
minute of the auger or other
fuel feeding system.
Efficiency %
91
The total efficiency of the
boiler
Max auger Curr. A
0.5
The maximum allowable
current drawn by the auger
excitation motor.
Curr. Detect latency sec
2
The time delay for the auger
current limit alarm
Grate Open T s
190
The run time of the grate
open/close actuator.
Combustion Data
Fuel Energy kW/kg
4.88
The energy of a kilogram of
used pellet. (Please refer to the
information on your pellet
package)
Modulator
PID
The power regulation metod of
the boiler. There are three
modes for power regulation.
(PID [Graph1], 5STEP [Graph2]
or fixed power [Graph3])
Mod. Delta :C
10
The power regulation to reduce
the power of the boiler.
Eg. : The boiler temp. 50 C
Mod.Delta : 10 C
Boiler begins to slow down
when it is reached to 40 C.
Hysteresis :C
2
The temperature overlimit.
E.g :
The temp.of the boiler is : 50 C
If the hysteresis is set 2 C.
the boiler operates between
50-51 C. If it exceeds the 51 C
,it deflates the flame.
Feed Period :C
15
The fuel consumption to reach
the capacity :
E.g : If the feed period is set 15
it feeds 5 gr in every 15 sec.
If the feed period is set 20 it
feeds 7 gr.
If the feed period is set 25.
It feeds 9 gr.fuel in every 25 sec
