6 LIMITS OF USE
OPDE DC-DC has to be installed inside an electrical panel, which can also not be conditioned. In this case, the
environmental limits of use are given below.
CLIMATIC CONDITIONS 6.1
Environmental parameter
Limits
Measure
ment unit
Operating temperature
-20÷50
°C
Humidity
5÷95
%
Atmospheric pressure
70÷106
(1)
kPa
Maximum movement of the surrounding air
1
m/s
Maximum temperature gradient
0.5
°C/min
Maximum thermal radiation
700
W/m
2
Condensation
NO
Rainfall with wind
NO
(2)
Water of different origin from rain
NO
Icing
NO
(1)
The air pressure limits correspond to an operating field of 02000m a.s.l. In fact, over
1000 m above sea level, it is necessary to derate the rated current of the converter by 1%
per 100 m.
(2)
The converter must be installed inside an electrical panel and, therefore, not outdoor.
TAB. 7 – Climatic conditions
RESISTANCE TO CHEMICALLY ACTIVE SUBSTANCES 6.2
3C1R class according to EN 60721-3-3
Environmental
parameter
Maximum
value
Measurem
ent unit
Environmental
parameter
Maximum
value
Measurem
ent unit
Sea salts
NO
-
Hydrofluoric acid
0.001
0.0012
mg/m
3
cm
3
/m
3
Sulfur dioxide
0.01
0.0037
mg/m
3
cm
3
/m
3
Ammonia
0.03
0.042
mg/m
3
cm
3
/m
3
Hydrogen sulfide
0.0015
0.001
mg/m
3
cm
3
/m
3
Ozone
0.004
0.002
mg/m
3
cm
3
/m
3
Chlorine
0.001
0.00034
mg/m
3
cm
3
/m
3
Nitrogen oxide
0.01
0.005
mg/m
3
cm
3
/m
3
Hydrochloric acid
0.001
0.00066
mg/m
3
cm
3
/m
3
TAB. 8 – Resistance to chemically active substances
RESISTANCE TO VIBRATIONS 6.3
As regards vibrations, the limits of use are the following:
10Hz  frequency  57Hz
0,075
mm (amplitude)
57Hz  frequency  150Hz
1
G
TAB. 9 – Vibrations
In the case of vibration above the indicated limits, it is necessary to adopt suitable damping solutions.
PROTECTION AND POLLUTION DEGREE 6.4
Protection degree
IP00
Pollution degree
2
TAB. 10 – Protections
