7.2.2 EXAMPLES OF CONNECTION
In order to be used in energy conversion applications, the OPDE DC-DC converter must be connected to other
additional components necessary for its proper operation, in fact the OPDE DC-DC converter is a power and control
unit of a four-IGBT bridge.
Externally, it is necessary to connect:
- an LC filter;
- a precharge circuit (optional);
- electromechanical devices for disconnecting and/or protecting the DC input and DC output side;
- other control devices if required (including insulation controllers and Residual Current Devices);
- EMC filters.
Normally, the OPDE DC-DC converter and the other external components are installed inside an electric cabinet that
will be the final and complete electrical equipment.
Please refer to the chapters Errore. L'origine riferimento non è stata trovata. for examples for the correct connection
of the OPDE DC-DC converter.
