TDE MACNO BDF DIGITAL OPDE SD 22 - Page 54

52
MP01200E00 V_1.0
Output inductors L1-L2
Size OPDE SD
OPDE SD
175
OPDE SD
220
OPDE SD
250
Inductance [mH]
[mH]
0.785
0.614
0.543
Effective thermal current [Arms]
[Arms]
109.7
140.2
158.6
Effective overload current [Arms]
[Arms]
125.4
160.2
181.2
Overload
120% 30s
Rated voltage [Vdc]
[Vdc]
830
Rated frequency [Hz]
[Hz]
0
Current THD [% of thermal current]
[%Ith]
7.3
Switching frequency [kHz]
[kHz]
10
Ambient temperature [° C]
[°C]
50
Cooling
Natural ventilation
Overtemperature class
F
Insulation class of materials
H
Insulation voltage [kV]
[kV]
1.1 / 3 for 30s
BDF Digital code
054R47011
054R47012
054R47013
TAB. 25B - Output inductors
Output inductors L1-L2
Size OPDE SD
OPDE SD
310
OPDE SD
370
OPDE SD
460
Inductance [mH]
[mH]
0.440
0.369
0.298
Effective thermal current [Arms]
[Arms]
195.8
233.1
288.8
Effective overload current [Arms]
[Arms]
223.8
266.4
330
Overload
120% 30s
Rated voltage [Vdc]
[Vdc]
830
Rated frequency [Hz]
[Hz]
0
Current THD [% of thermal current]
[%Ith]
7.3
Switching frequency [kHz]
[kHz]
10
Ambient temperature [° C]
[°C]
50
Cooling
Natural ventilation
Overtemperature class
F
Insulation class of materials
H
Insulation voltage [kV]
[kV]
1.1 / 3 for 30s
BDF Digital code
054R47014
054R47015
054R47016
TAB. 26B - Output inductors
