3 NAME OF THE DEVICE
The device in question is called as follows: OPDE DC-DC
The code OPDE-SD DC-DC that is shown on the device label is described below.
Level
6= level 6
OPDE
D1= OPDE
Type
D= OPDE-SD DC-DC
Size
022= 22A - 032= 32A - 040= 40A - 048= 48A - 060= 60A - 070= 70A -
090= 90A 110= 110A 150= 150A (CASE1 C) - 175= 175A - 220=
220A - 250= 250A (CASE2) - 310= 310A - 370=370A - 460= 460A
(CASE3)
Overload
X= Standard (5kHz PWM) (All possible overloads)
C= 3 kHz PWM
Mains voltage
5D= 560V VDC
Drive
M= Drive + Reg. → 24V external (case1C, 2, 3)
Brake
0= NO BRAKE
Speed sensor 1
0= no feedback
Speed sensor 2
0= no feedback
Fieldbus
0= No fieldbus
1= Profibus
3= Can Bus
4= Ethercat
5= Hsc (high speed communication)
I/O
0= No U= Display + I/O + RS485 serial line OPTO + USB port
X= Display + I/O + RS485 serial line OPTO
Field
0= Standard
Customization
V= standard BDF Digital (a different letter refers to a specific
customization)
1
D
D
5
6
D
M
0
0
0
0
V
