TDT RZ2 - Page 671

System 3 18-13
PP24 Patch Panel
The diagram below maps the RZ2 Analog I/O connection to the PP24.
MappingRZ5,RZ5DI/O
Note: The PP24 is mounted below the RZ5.
The diagram below maps the RZ5 or RZ5D Digital I/O connection to the PP24.
A1-A8 B1-B8 C1-C8
Bit Addressable Digital I/O
Channels 0-7
Digital I/O, Port A
Channels 0-7
Digital I/O, Port B
Channels 0-7
A1-A8 B1-B8 C1-C8
Not Used
Analog Input, Port D
Channels 1-8
Analog Output, Port E
Channels 9-16
A1-A8 B1-B8 C1-C8
Bit Addressable Digital I/O
Channels 0-7
Digital I/O, Byte A
Channels 0-7
Digital I/O, Byte B
Channels 0-7
