System 3 1-89
RZ-UDP Communications Interface
TypicalRZTransmissionPerformancewiththeRZUDP‐20Table
The table below displays the expected throughput for different numbers of packets
sent or received per second depending on the number of channels transmitted on an
RZ processor.
TechnicalSpecifications
Number of Channels
(32-bit Words)
Packets Sent/Received
per Second
1600
8500
16 400
32 300
64 150
128 100
192 50
Interfaces
Standard Ethernet (for direct connections to a PC
an Ethernet crossover cable is required) RS-232
Serial Port (9-Pin)
Ethernet Speed
10 Mbps
Serial Speed
115,200 bits/sec
Supported Network DHCP (Dynamic
Host Protocols
Configuration Protocol), UDP, HTTP (for
configuration)
Transfer Rates
Dependent on data packet size (see Typical RZ
Transmission Performance with the RZUDP-20
Table above)
