TE Technology TC-720 User Manual

65
(+)
(-)
TE DEVICE (LOAD)
POWER
+
-
USB
COMMUNICATION
I
N
P
U
T
S
O
U
T
P
U
T
S
C
O
N
T
R
O
L
L
O
G
I
C
JP2-1 CONTROL SENSOR (+)
JP2-2 CONTROL SENSOR (-)
JP2-3 SECONDARY SENSOR (-)
JP2-4 SECONDARY SENSOR (+)
JP2-5
0 TO 10 V OUTPUT DRIVE, OR 0 TO 20 mA AT 5 V
(0 TO 100%)
COMPLIANCE WITH 249 OHM RESISTOR FROM
JP2-5 TO GROUND
JP2-8
ALARM 1
OPEN DRAIN; 36 V, 2 A MAXIMUM
JP2-10
ALARM 2
OPEN DRAIN; 36 V, 2 A MAXIMUM
JP7-1
JP7-2
JP7-3
POWER GROUND
JP7-4
V+ IN, TE
JP2-9
LOGIC SUPPLY +
JP2-7
LOGIC SUPPLY -
249 OHMS
JP2-6 INTERLOCK
2500 OHMS
+5 V
10000 OHMS
