TC-720 Mechanical Package Drawing
149.1
137.855.64
97.92
121.67
11
5.61, TYP
120
35.8
1.5
LIQUID CRYSTAL DISPLAY
2X16 CHARACTERS
USB LED, WHITE
ALARM LED, ORANGE/GREEN
JP7
PIN 1
2
2
3 4
345678910
JP2
PIN 1
USB COMMUNICATION PORT
(JP3)
NOTE: All dimensions are in millimeters
