Tape
Dubbing
The
“2
1"
and
“1/DAT
»
2”
(TAPE
DUB)
positions
of
the
REC
SELECTOR
allow
you
to
copy
between
two
tape
decks.
While
dubbing
is
being
performed,
you
can
listen
to
another
source
without
affecting
the
dubbing
Example:
To
dub
from
the
deck
connected
to
TAPE
1/DAT
to
the
deck
connected
to
TAPE
2:
1.
Set_the
REC
SELECTOR
to
the'1/
DAT
»
2”
position
2.
Set the
playback
deck
(Deck
1}
to
the
playback
mode,
and
the
recording
deck
(Deck
2)
to
the
record
mode,
adjusting
the
recording
level
suitably.
(Refer
to
the
owner's
manuals
of
the
decks.)
3.
Set
the
INPUT
SELECTOR
switch
to
the
TAPE
1/DAT
position
or
plug
the
headphones
into
the
PHONES
jack
of
the
tape
deck
used
for
recording
to
monitor
the
sound
being
copied.
ATTENTION:
Copyrighted
material
must
not
be
dub-
bed.
Specifications
Continuous
Power
Output:
RMS:
75
W+75
W
(20
20,000
Hz,
8
ohms,
THD
0.009
%)
100
W
+
100
W
(20
20,000
Hz,
4
ohms,
THD
0.025
%)
DIN
(1
kHz):
85
W
+85
W
(8
ohms)
120
W
+
120
W
(4
ohms)
Dynamic
Power
Output
(EIA)
100
W
+
100
W
(8
ohms)
150
W
+
150
W
(4
ohms)
Total
Harmonic
Distortion
0.007
%
(1
kHz,
8
ohms,
continuous
rated
power
output)
0.009
%
(20
20,000
Hz,
8
ohms,
continuous
rated
power
output)
0.01
%
(1
kHz,
4
ohms,
continuous
rated
power
output)
0.025
%
(20
20,000
Hz,
4
ohms,
continuous
rated
power
output)
Input
Sensitivity/Impedance:
Phono
MM/MC:
2.5
mV
(47
kohms)/
250
zV
(100
ohms)
CD,
TUNER,
AUX,
TAPE1/2/3:
150
mV/30
kohms
Signal-to-Noise
Ratio
(IHF-A):
Phono
MM/MC:
80
dB
(5
mv)/
67
dB
(500
uv)
Line:
101
dB
Output
Level/Impedance:
TAPE
1/DAT,
TAPE
2,
TAPE
3:
150
mV/1
kohms
Frequency
Response:
PHONO:
20
20,000
Hz,
+0.5
dB
(RIAA)
CD,
TUNER,
AUX,
TAPE
1/2/3:
5
100,000
Hz,
-3
dB
Tone
Control;
Bass:
+10
dB
(100
Hz)
Treble:
£10
dB
(10
kHz)
Loudness
Contour:
+8/+6
dB
at
100
Hz/10
kHz
Subsonic
Filter
:
15
Hz
(6
dB/oct.)
Muting
:
-20
dB
Power
Requirements/Power
Consumption:
115/230
V
AC,
50/60
Hz,
700
W
(General
Export)
120
V
AC,
60
Hz,
330
W
(USA)
120
V
AC,
60
Hz,
630
VA
(Canada)
220
V
AC,
50
Hz,
700
W
(Europe)
240
V
AC,
50
Hz,
860
W
(UK/Australia)
Dimension
(W
x
H
x
D):
435
x
155
x
354
mm.
Weight
(net):
10.5
kg
Improvements
may
result
in
feature
and
specification
change
without
notice
Précautions
a
prendre
Mise
en
place
de
l'appareil
Cet
appareil
étant
un
amplificateur
de
puissance
importante,
il
dégage
de
la
chaleur
par
I‘arriére
ainsi
que
par
le
haut.
Il
est
donc
conseillé
de
poser
cet
amplificateur
dans
un
endroit
bien
aéré,
Eviter
les
endroits
ot
la
températeure
est
élevée,
|’exposition
au
soleil,
I'humidité
et
la
poussiére,
Des
cor-
dons
excessivement
longs,
surtout
ceux
des
enceintes,
sont
susceptibles
de
provoquer
une
altération
sonore,
il
est,
par
conséquent,
recommandé
d’employer
des
cordons
de
raccordement
aussi
sourts
que
possible.
Changement
de
tension
(Modéles
d’exportation
générale
seulement)
BIEN
DEBRANCHER
LE
CORDON
D’ALI-
MENTATION
DE LA
PRISE
SECTEUR
AVANT
DE
REPOSITIONNER
LE
SELECTEUR
DE
CHANGEMENT
DE
TEN-
SION.
1.
Localiser
le
sélecteur
de
tension
sur
le
panneau
arriére.
2.
En
utilisant
un
tournevis
a
lame
plate,
régler
sur
la
position
appropriée
230
V
ou
115V
en
fonction
de
la
tension
locale,
VOLTAGE
SELECTOR
vsv230V
a
|
Commandes
et
connecteurs
Panneau
avant
@
Interrupteur
d’alimentation
(POWER)
Appuyer
pour
mettre
—_‘alimentatio.
Appuyer
a
nouveau
pour
couper
l’alimenta-
tion.
Quand
I'alimentation
est
mise,
|'indicateur
au-dessus
de
I‘interrupteur
s‘allume.
@
Prise
de
casque
d'écoute
(PHONES)
Cette
prise
est
pour
le
raccordement
d.un
casque
d’écoute
stéréo
avec
une
fiche
stéréo
standard
1/4"
(6,35
mm
de
diamétre)
©
Touches
de
sélection
de
haut-
parleurs
(SPEAKERS)
Ces
touches
sont
utilisées
pour
sélectionner
les
enceintes
acoustiques
A
et/ou
B,
Remarque:
Si
une
enceinte
acoustique
avec
une
im-
pédance
de
moins
de
6
ohms
raccordée,
ne
pas
appuyer
simultanément
sur
les
touches
SPEAKERS
A
et
B.
@Commandes
de
tonalité
(BASS/
TREBLE)
Ces
deux
commandes
de
tonalité
