Pin No. Symbol Description
46 T_MUTE Output for tuner mute. (At "L", it is active.)
47 SR_MUTE Output for surround channel mute. (At "L", it is active.)
48 SW_MUTE Output for sub woofer channel mute. (At "L", it is active.)
49 C_MUTE Output for center channel mute. (At "L", it is active.)
50 F_MUTE Output for front channel mute. (At "L", it is active.)
51 VIDEO_S3 Video select 1,2,3
52 VIDEO_S2 Video select 1,2,3
53 DSP_MUTE Output for DSP mute. (At "L", it is active.)
54 NC Not used!
55 CS4926RST Reset signal output to CS4926.
56 ROM2 Signal output to M27W201 .
57 ROM30 Signal output to M27W201 .
58 ROM3 Signal output to M27W201 .
59 AUTOBOOT Output for DSP AUTOBOOT
60 SUB SUM Output for sub woofer Summing. (At "L", it is active.)
61~66 N.C Not used!
67 SPK_LED
Output to drive speaker LED. (At "H", it is active.)
68 CS 4112 Chip select signal output to AK4112
69 STANDBY LED/RELAY Output to drive Power on,standby LED. (At "H", it is active.)
70~85 S1~S15 GRID FL PORT
86 N.C Not used!
87 N.C Not used!
88 N.C Not used!
89 VDD +5V power supply.
90 N.C Not used!
91~100 G1~G10 GRID FL PORT
