1 CGU1A375Z WINDOW
2 CBN1A122 KNOB, VOLUME
3 CMC1A140 RING, SHAFT
4 CGX1A369Z SHEET, LED
5 CGX1A370Z SHEET, LED
6 CGB1A165H12 BADGE, TEAC
7-1 CGW1A405R4YH10 PANEL, FRONT(EUR) [EUR,UK]
7-2 CGW1A405R4ZH10 PANEL, FRONT(230E-N) [230E-N,HKG]
8 KHS1A032 TAPE, HEMELON
9 CMD1A563 BRACKET
10 HJJ2E020Z PHONE JACK
11 CUP11805-7 PCB
12 CWE7202100RV WIRE ASS'Y
13 CMK1A010 BRACKET
14 CBT1A991 KNOB, SPEAKER
15 CBC1A152 KNOB, POWER
16 CBT1A992 KNOB, TUNING
17 CMD1A334 BRACKET 1
18 KSH1A001ZV MOMS SWITCH
19 CUP11805-8 PCB
20 CBT1A994 KNOB, BASS
21 CBT1A993Z KNOB, FUNCTION
22 HFLSVA09MS10 FIP
23 CMD1A374 BRACKET, FIP
24-1 CUP11805-1 PCB, FRONT
24-2 CUP11805-2 PCB, FRONT
25 CMY1A256 SINK, HEAT
26 CMD1A417 BRACKET, PCB
27 CUP11805-11 PCB
28 CUP11805-3 PCB
29 CLT5U012YE TRANS
30 CUP11805-4 PCB
31 CUP11805-10 PCB
32 CUP11805-9 PCB, POWER
33 CHG1A113 RUBBER
34 CUA2A168 CHASSIS, BOTTOM
35 CKL2A042H11 FOOT, FRONT
36 KHG1A050Y CUSHION, FOOT
37 CKL1A012 FOOT, RUBBER
38-1 CNVMB114MA18L TUNNER PACK(EUR) [EUR,UK]
38-2 CNVKSTMB014MA18 TUNNER PACK(230E-N) [230E-N,HKG]
39 CMD1A571 BRACKET, SUPPORT
40 CUP11806-1 PCB, MAIN
41 CUP11806-2 PCB
42 CHE1A023 MOUNT, PCB
43 CMD1A392 BRACKET, PCB
44 CKF4A172Z PANEL, REAR
45 KMD2A001 TERMINAL, GROUND
46 KHR1A028 BUSHINHG, AC CORD
47-1 CJA2B043ZA CORD, POWER [EUR,230E-N]
47-2 CJA2B045ZA CORD, POWER [UK,HKG]
48 CKC1B098S1 CABINET, TOP
S1 CTB3+8J SCREW
S2 CTB3+10J SCREW
S3 CTB3+10G SCREW
S4 CTB3+6J SCREW
S5 CTB3+8JFZ SCREW
S6 CTB3+10GFZ SCREW
S7 CTB4+8F SCREW
S8 CTB4+6FFZ SCREW
S9 CTW3+8J SCREW
S10 CTW3+16G SCREW
S11 CTWS3+8G SCREW
－12－
EXPLODED VIEW LIST
(AG-790A) [EUR,UK,230E-N,HKG]
