Teac AG-D8900 - Page 27

INPUT PCB ASSY
REF.NO. PARTSNO. DESCRIPTION
9A08888000 INPUTPCBASSY[J]
9A08888010 INPUTPCBASSY[US,C]
9A08953300 PCB,INPUT
9A08215300 PACK,FRONTEND[US,C]
9A08947100 PACK,FRONTEND[J]
ANT1 9A07371900 TERMINAL,ANT
BN13,BN14 9A08036700 WAFER
CF11,CF12 9A06544600 FILTER,CERAMICE107MSHAT
CF22 9A07006300 FILTER,CERAMICPBF450JR3
CN10 9A08947300 WAFER,CARDCABLE
CN11 9A08947400 WAFER,CARDCABLE
CN41 9A05356300 WAFER,04GA19ZM
CT10 9A01405900 C,VARIABLE20PF
D101 9A08163000 DIODE,VARICAPSVC342‑L‑AA
D110,D113 9A08878200 DIODE,1SS133T‑77
D150 9A07892400 DIODE,ZENER9.1V1/2W
D190 9A08954100 DIODE,ZENERMTZJ5.1BT
D301,D302 9A08951100 DIODE,ZENERMTZJ6.8BT
D303 9A08954100 DIODE,ZENERMTZJ5.1BT
D401 9A08954200 DIODE,1N4148T
D451 9A08954300 DIODE,ZENERMTZJ4.7BT
D490 9A08878200 DIODE,1SS133T‑77
IC11 9A08947500 IC,PLL
IC12 9A08033000 IC,LA1837
IC20 9A08947600 IC,KIC9164AF
IC21 9A08947700 IC,KIC9163AF
IC22 9A08889900 IC,LA6462M
IC23‑IC26 9A08947800 IC,LA6458M
IC31 9A08947900 IC,M62446FP
IC32,IC34 9A08889900 IC,LA6462M
IC33,IC35 9A08947800 IC,LA6458M
IC40 9A08948000 IC,TC74HCU04AFN
IC41 9A08948100 IC,AK4112A‑VF‑E2
IC42 9A08903900 IC,AK4527VQ
IC43 9A08033700 IC,YSS912C‑F
IC45 9A08032900 IC,IS61C256AH‑15J
IC51,IC52 9A08948200 IC,LA7952
JK11,JK12 9A07425400 JACK,IN/OUT
JK13 9A07425500 TERMINAL,IN/OUT
JK15,JK16 9A08948300 MODULE,OPTICALTORX178A
JK17 9A08948400 JACK,BOARD(2P)
JK51 9A08948500 JACK,S‑VIDEO(3P/H)
L104 9A08948600 COIL,MWANT
L105 9A07873300 COIL,AMOSC
L403 9A08037600 COIL,10UH
L405 9A08037600 COIL,10UH
L406,L407 9A07050600 BEAD,CORE
L408 9A08037600 COIL,10UH
Q106 9A08954400 TR,KTC3194OT
Q112 9A08884100 TR,KRA107M
Q114 9A08878300 TR,KRC107M
Q401 9A07888000 TR,KSC2316YT
R102£ 9A08948700 R,CARBON4.7OHM1/2WJ
T101 9A08125500 IFT,FM
T102 9A08948900 IFT,AM
INPUT PCB ASSY
REF.NO. PARTSNO. DESCRIPTION
VR11 9A08040600 R,SEMI‑FIXED10KOHM
VR12 9A08040700 R,SEMI‑FIXED22KOHM
VR13 9A08040600 R,SEMI‑FIXED10KOHM
X101 9A08883700 CRYSTAL
X401 9A08949000 CRYSTAL
FRONT PCB ASSY
REF.NO. PARTSNO. DESCRIPTION
9A08887000 FRONTPCBASSY[J]
9A08887010 FRONTPCBASSY[US,C]
9A08949100 PCB,FRONT
BK71,BK72 9A08888700 BRACKET,FLT
CH94,CH95 9A08889400 CONNECTOR,HOUSING
CN10 9A08889500 WAFER,CARDCABLE
CN11 9A08889600 WAFER,CARDCABLE
CN16 9A08036300 WAFER
CN17 9A07335100 WAFER,MOLEX53015
CN71 9A07049700 WAFER
CN74 9A07049500 WAFER,MOLEX53015‑0310
CN83 9A05329100 WAFER,MOLEX5267‑03A
CN91 9A06759300 WAFER
CN92 9A05329300 WAFER,MOLEX5267‑04A
CW13,CW14 9A08036600 WAFER,MOLEX35336‑1010
D701‑D703 9A08147300 LED,SLR342VCTB7(RED)
D704‑D707 9A08878200 DIODE,1SS133T‑77
D751 9A08878200 DIODE,1SS133T‑77
D811,D812 9A08878200 DIODE,1SS133T‑77
D901£ 9A08889700 DIODE,BRIDGE
D903‑D908£ 9A05194700 DIODE,1N4003ST
D911 9A08905700 DIODE,ZENERMTZJ30BT
D912 9A07887100 DIODE,ZENER6.2V
EP71 9A05961500 PLATE,EARTH
FIP1 9A08034600 FIP,SVA‑10MS11
F903,F904 9A05328200 HOLDER,FUSE
IC71 9A08889800 IC,TMP87PM78F
IC73 9A08889900 IC,LA6462M
JK71‑JK73 9A08890000 JACK,VCR
JK74 9A07491600 JACK
L701 9A07886600 COIL,10UH
Q701 9A08905800 TR,KRA104MT
Q702 9A08905900 TR,KRC114MT
Q703,Q704 9A08878300 TR,KRC107M
Q705 9A07887900 TR,KSB811YT
Q706‑Q708 9A08878300 TR,KRC107M
Q901 9A08906000 TR,KTA1271YT
RS71 9A08563600 SENSOR,REMOCON
R901‑R904£ 9A05897200 R,FUSE0.47OHM1W
S701‑S718 9A07878500 SW,TACTSKHV10910G
VE71 9A08890200 VR,ENCODER2A004Z
VE72 9A08890300 VR,ENCODER2A006Z
VR71 9A08890400 R,VARIABLE(BALANCE)
VR72,VR73 9A08890500 R,VARIABLE(TONE)
X701 9A08879000 CRYSTAL
27
