Teac AG-D8900 - Page 28

MAIN PCB ASSY
REF.NO. PARTSNO. DESCRIPTION
9A08887900 MAINPCBASSY[J]
9A08887910 MAINPCBASSY[US,C]
9A08950900 PCB,MAIN
9A08952200 HEATSINK
9A08745400 BRACKET,PCB(H/T)
9A08952300 BRACKET,PCB
CN17 9A06250600 WAFER,02GA19ZM
CN73 9A05356500 WAFER,MOLEX53014‑0710
CN91 9A06674400 WAFER
CN92 9A06785000 WAFER
CN94,CN95 9A08891200 WAFER,08GA98ZM
CN96 9A05330000 WAFER,MOLEX5267‑07A
C903£ 9A08032200 C,LINEACROSS0.1UF250V
C904£ 9A08882700 C,CERAMICDE7150‑610F472M
C906£ 9A08944600 C,ELECT1000UF25V
C915,C916£ 9A08944700 C,ELECT8200UF63V
C917,C961£ 9A08944800 C,ELECT3300UF25V
C918£ 9A07897200 C,ELECT2200UF25V
D501,D502 9A08878200 DIODE,1SS133T‑77
D507,D508 9A08878200 DIODE,1SS133T‑77
D511‑D516 9A08878200 DIODE,1SS133T‑77
D581‑D585 9A08878200 DIODE,1SS133T‑77
D901£ 9A05194700 DIODE,1N4003ST
D902 9A08878200 DIODE,1SS133T‑77
D903‑D906£ 9A05194700 DIODE,1N4003ST
D911,D912 9A08878200 DIODE,1SS133T‑77
D914‑D917 9A08878200 DIODE,1SS133T‑77
D931 9A08878200 DIODE,1SS133T‑77
D951,D952 9A08951100 DIODE,ZENERMTZJ6.8BT
D953 9A08878200 DIODE,1SS133T‑77
ET01,ET03 9A08945000 PLATE,EARTH
ET02 9A08945100 BRACKET,PCB
F901,F902 9A05328200 HOLDER,FUSE
IC91 9A08952900 HEATSINK
IC91£ 9A07898500 IC,KA7812‑ABTU
IC92 9A08952900 HEATSINK
IC92£ 9A08953100 IC,KA7912‑ABTU
IC93 9A08953200 HEATSINK
IC93,IC95£ 9A08218600 IC,KA7805‑ABTU
IC96 9A08945500 IC,NJM2296M
JK91 9A08945600 TERMINAL,SPEAKER(4P)
JK92 9A08945700 TERMINAL,SPEAKER
JK97 9A07427800 JACK,VCR
JK98 9A08945800 JACK,BOARD
L501‑L505 9A08946000 COIL,SPEAKER
OL01£ 9A08946100 OUTLET,2P
Q511‑Q520 9A08951200 TR,KTA1268GRT
Q541‑Q545 9A08951200 TR,KTA1268GRT
Q556‑Q565 9A08951300 TR,KTC3200GRT
Q581‑Q585 9A08951200 TR,KTA1268GRT
Q611‑Q615 9A08952400 TR,KTD600K
Q621‑Q625 9A08946200 TR,2SA1360O
Q626‑Q630 9A08946300 TR,2SC3423O
Q642‑Q645£ 9A08946400 TR,KTD2061Y
Q646‑Q650£ 9A08946500 TR,KTB1369Y
MAIN PCB ASSY
REF.NO. PARTSNO. DESCRIPTION
Q656£ 9A08946400 TR,KTD2061Y
Q657‑Q660£ 9A08952600 TR,2SC4468
Q661‑Q665£ 9A08952700 TR,2SA1695
Q670£ 9A08952600 TR,2SC4468
Q681‑Q685 9A03745000 TR,KSC2785‑YTA
Q901,Q935 9A08878300 TR,KRC107M
Q938‑Q940 9A08884100 TR,KRA107M
Q942,Q943 9A03745000 TR,KSC2785‑YTA
Q951 9A08878300 TR,KRC107M
Q952 9A08884100 TR,KRA107M
Q953‑Q956 9A07888500 TR,KTD1302T
Q969‑Q973 9A07888500 TR,KTD1302T
Q991 9A08878300 TR,KRC107M
Q992 9A08884100 TR,KRA107M
RY93£ 9A08946600 RELAY,4A004ZU
RY94£ 9A08946700 RELAY,1A008ZE
R656‑R660£ 9A07331100 R,CEMENT0.22X25W
R904£ 9A06761000 R,CARBON3.3MK1/2W[US,C]
R905£ 9A05338000 R,METAL10OHM1WJ
R907,R908£ 9A07309700 R,METAL470OHM1WJ
R958,R959£ 9A08946800 R,CARBON120OHM1/2WJ
R993‑R997£ 9A05338000 R,METAL10OHM1WJ
TH91 9A08039800 THERMALSENSOR,POSISTOR
T901£ 9A08946900 TRANSFORMER,SUB
28
