Teac CD-P6000 - Block Diagram

CD-P6000/CD-30
14
6 BLOCK DIAGRAM
ブロックダイアグラム
TOP TCL
OUT SW IN SW
TRAY MOTOR
A
C
B
D
E
F
LD
PD
PICK UP
FCS+ FCS- TRK+ TRK-
E F LD PD
LIMIT SW
SLED+
SLED-
SPINDLE+
SPINDLE-
SERVO MOTOR
CD MECHA
SERVO DRIVER
LD_ON
FE TE
TE
FE
SSTP
DSP CXD2598Q
FFDR FRDR TFDR TRDR SFDR SRDR MDP
DOUT SCOR SQSO SQCK DATA XLAT CLOK SENS FOK LOCK
SIO1 SIO0
MICOM CXP82532
KEY MATRIX
FL DISPLAY
RF_AMP CXA2568M
A B C D
RF
RF
LRCK V16M PCMD BCK EMPH
BLCK EMPH SDATA LRCK XTI
DAC AK4319
+
+
AOUTL AOUTR
L CH R CH LINE OUT
2 3 1
GN1 GND
(CD-P6000 only)
DIGITAL OUT (FRONT) DIGITAL OUT (REAR)
