Functional Overview
Rear Panel
L R
VIDEO/ Y
Pb Pr
1 2 3 7 4 4
COAX AV IN YPBPR HEADPHONE HDMI1/ARC HDMI2
COAX: Connection for Digital Coaxial input for Audio Amplifier.
AV IN: Video and Audio (L/R) input Terminal, Audio (L/R) can be used as YPBPR Audio input.
YPbPr input terminals: Connect to equipment with component video output.
HDMI 1 /HDMI 2/3/4 Input terminal: Connect to equipment with antenna output or wall antenna socket.
Antenna Input terminal: Connect to equipment with antenna output or wall antenna socket.
USB: Insert USB flash drives or hard disk drives.
HEADPHONE: Connect to headphones or compatible audio amplifiers.
4 5 6
RF USB
HDMI3/HDMI4
1
2
3
4
5
6
7
8
