Teac P-70 - Connection Guide; D;A Converter and Recording Equipment Setup

8
Connection
1
P-70
DIGITAL IN
DIGITAL IN
WORD SYNC
OUT
SIGNAL GND
XLR(R)
XLR(L)
D/A converter
BNC coaxial cable
Optical digital cable
Power cord
(included with the player)
Wall socket
Connect one of
these cables
XLR cable
RCA coaxial cable
XLR (balanced) pin numbers
Optical digital cable
Digital recording equipment such
as CD recorder, MD deck, etc.
2
3
4
