−12−
EXPLODED VIEW-2
REF.NO. PARTSNO. DESCRIPTION REMARKS
2‑1£ 9A09117000 SW,PUSHP12
2‑2 9A09143200 POWERKNOB
2‑3 9A09143700 LOGOPLATE
2‑4 9A09143400 SPKTRIM
2‑5 9A09140200 SWPCBASSY
2‑6 9A09143000 SPK,CAB
2‑7 9A09145200 SCREW,T2.6XP1.07XL8.0MM
2‑8 9A09143900 PORTTUBE,OD65XID55XL155M
2‑9 9A09145600 SPONGE,OD118XID50XT10MM
2‑10 9A09144100 WOODBOX[EXCEPTJ]
9A09197300 WOODBOX[J]
2‑11 9A09144200 SPKDRIVER,100W6.5INCH4OHM
2‑12 9A09144600 SCREW,M3.5X14MMBLK
2‑13 9A09143100 GRILLE
2‑14 9A09145100 SCREW,M3X10BLK
2‑15 9A08755900 SCREW,T3.0XL8.0XP1.06MM
2‑16 9A09146000 COVERSPONGE,L34XW4.5XT3MM
2‑17 9A09142800 REARCOVER
2‑18 9A09144600 SCREW,M3.5X14MMBLK
2‑19 9A09197400 REARPLATE[J]
9A09144400 REARPLATE[US,C]
9A09249100 REARPLATE[HK,SG,E,K,UK,SAF,F]
9A09249200 REARPLATE[NZ]
2‑20 9A09133600 JACKSWITCHPCBASSY
2‑21 9A09145300 FIBER,DIA12XID3.5XT1.6MM
2‑22 9A09134100 AMPPCBASSY
2‑23 9A09142900 FOOT,D25XL25
2‑24 9A09144700 SCREW,T4X20MMBLK[EXCEPTJ]
9A09197600 SCREW,T4X25MMBLK[J]
2‑25 9A09145400 RUBBERPAD,D20XT3MMBLK
2‑26£ 9A09274700 PWRTRANSFORMER,100V[J]
£ 9A09146500 PWRTRANSFORMER,120V[US,C]
£ 9A09274800 PWRTRANSFORMER,230V[HK,SG,E,K,UK,SAF,NZ,F]
2‑27 9A09116500 NUT,M4.0XOD7.0XT3.0MM
2‑28 9A09144300 BRACKET,X'FORMER
2‑29 9A09143500 RUBBERPAD,50X12XT2MM
2‑30 9A09144900 SCREW,M4X25X0.7MMBLK
2‑31£ 9A09143800 BUSHING
2‑32£ 9A07441300 LINECORD[J]
£ 9A09146600 LINECORD[US,C]
£ 9A09420200 LINECORD[HK,UK]
£ 9A09420300 LINECORD[SG,E,SAF,F]
£ 9A09420400 LINECORD[K]
£ 9A07469800 LINECORD[NZ]
2‑33 9A09143300 LEDLENS
