Teac PL-D2000 - SYSTEM FEATURES AND DISC INFORMATION

−7−
3. FM MONO DISTORTION ADJUSTMENT FMMONO歪率調整
AC VOLT METER ........................Connect to the output.
Signal Generator........................Connect to FM ANT Jack (FM IN) through the dummy.
Distortion Meter .........................Connect to the output.
NO. Frequency Adjust for Adjustment
1
98.10MHz [EUR,US]
82.00MHz [J]
FE001中周
Minimum T.H.D
(<1%)
4. FM/AM AUTO STOP LEVEL CHECK FM/AMオートストップレベル確認
FM SIGNAL GENERATOR ........................Connect to FM ANT Jack (FM IN) through the dummy
AM SIGNAL GENERATOR.........................Connect to AM ANT, Coil through the Loop antenna
BAND STEP SIGNAL GENERATOR Check Result
1
90.10MHz [EUR,US]
78.00MHz [J]
≦32dB OK/NG
2
106.10MHz [EUR,US]
88.00MHz [J]
≦32dB OK/NG
1
612kHz [EUR,J]
610kHz [US]
≦84dB OK/NG
2
1404kHz [EUR,J]
1400kHz [US]
≦84dB OK/NG
AM
FM
TUNED
TUNED
TUNED
TUNED
AC
