Teac PL-D2000 - Table of Contents; Safety Information

1 SAFETY INFORMATION
−2−
This product has been designed and manufactured according to
FDA regulations "title 21, CFR, chapter 1, subchapter J, based on
the Radiation Control for Health and Safety Act of 1968", and is
classified as a class 1 laser product. There is no hazardous
invisible laser radiation during operation because invisible laser
radiation emitted inside of this product is completely confined in
the protective housings.
The label required in this regulation is shown 1.
OCAUTION
USE OF CONTROLS OR ADJUSTMENT OR PERFORMANCE OF
PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY
RESULT IN HAZARDOUS RADIATION EXPOSURE.
Optical pickup:
Type : HOP-1000
Manufacturer : Hitachi Media Electronics Co., Ltd.
Laser output : Less than 0.5 mW on the objective lens
Wavelength : 770 - 810 nm (CD), 635 - 665 nm (DVD)
1
For U.S.A.
CONTENTS
1 SAFETY INFORMATION
・・・・・・・・・・・・・・・・・・・・・・
2
SAFETYINFORMATION
2 SPECIFICATIONS
・・・・・・・・・・・・・・・・・・・・・・・・・・・・・
3
仕様
3 ADJUSTMENT AND CHECKS
・・・・・・・・・・・・・・・・
5
調整と確認
4 EXPLODED VIEWS AND PARTS LIST
・・・・・・・・
8
分解図とパーツリスト
5 PC BOARDS AND PARTS LIST
・・・・・・・・・・・・・・
15
基板図とパーツリスト
6 BLOCK DIAGRAM
・・・・・・・・・・・・・・・・・・・・・・・・・・・
23
ブロック図
7 WIRING DIAGRAM
・・・・・・・・・・・・・・・・・・・・・・・・・・・
24
結線図
