−14−
EXPLODED VIEW-3
REF.NO. PARTSNO. DESCRIPTION REMARKS
3‑1 9A09118200 GRILLE
3‑2 9A08755900 SCREW,T3.0XL8.0XP1.06MM
3‑3 9A09118600 SPKDRIVER,25W3INCH4OHM(REAR)
9A09118700 SPKDRIVER,25W3INCH4OHM(FRONT/CENTER)
3‑4 9A09118900 SPONGE,OD79XID70XT3.0MM
3‑5 9A09118000 SPKPANEL(FRONT/REAR)
9A09118100 SPKPANEL(CENTER)
3‑6 9A09119100 SPONGE,L123XW5XT1MM
3‑7 9A09117800 REARCOVER
3‑8 9A08755800 SCREW,T3.0XL10.0XP1.06MM
3‑9 9A09118300 SPKJACK,2PBLK‑RED(FRONT)
9A09118400 SPKJACK,2PBLK‑BLU(CENTER)
9A09118500 SPKJACK,2PBLK‑GRY(REAR)
3‑10 9A09118800 SCREW,T4X12MMBLK
