Teac PL-D2000 - REMOTE CONTROL UNIT; BATTERY INSTALLATION AND REPLACEMENT

−17−
KEY PCB
TUNER PCB POWER PCB
REGIONAL JW281 JW282 JW283
1
1 1 1
2
1 1 0
3
1 0 1
4
1 0 0
5
0 1 1
6
0 1 0
JUMPER WIRE SETUP:
1=INSTALL, 0=NOT INSTALL
