MAIN PCB ASSY
REF.NO. PARTSNO. DESCRIPTION
9A09113100 MAINPCBASSY
[J,US,C,HK,SG,K,SAF,NZ]
9A09113140 MAINPCBASSY[E,UK,F]
9A09128400 MAINPCB
9A08773200 WASHER,ID=3OD=6H=2.5MM
9A09125300 HEATSINK
9A08290700 MICA
9A09125600 BRACKET
9A09116000 SCREW,M3X6X0.5P
9A09116300 SCREW,T3.0XL8.0XP1.06MM
C455 9A09125200 SLEEVING,OD2XID1XL5MM
C905,C907£ 9A08829500 C,ELECT6800UF/25V20%
C926,C945£ 9A08829400 C,ELECT3300UF/25V20%
C935£ 9A09126000 C,ELECT,2200UF/25V20%
CN001 9A08299800 CONNECTOR,TUC‑P10P‑B1
CN201 9A09124600 CONNECTOR,12PIN
CN301 9A09124500 CONNECTOR,7PIN
CN601A 9A09027100 CONNECTOR,TUC‑P15P‑B1
CN902 9A09124400 CONNECTOR,B9B‑XH‑A9PIN
CN903 9A07466200 CONNECTOR,CL3962WVO3PIN
CN904 9A08300100 CONNECTOR
D401 9A07449400 DIODE,1N4148
D501‑D504 9A07449400 DIODE,1N4148
D507‑D510 9A07449400 DIODE,1N4148
D901£ 9A09126700 RECTIFIER,KBU8B
D906,D907 9A07466400 SLEEVING,OD3.0XID2.5XL10
D906,D907£ 9A07462200 RECTIFIER,1N5401
D908,D909£ 9A07461600 RECTIFIER,1N4001
D910 9A07466400 SLEEVING,OD3.0XID2.5XL10
D910 9A07462200 RECTIFIER,1N5401
D911,D912£ 9A07461600 RECTIFIER,1N4001
D913‑D916 9A07461600 RECTIFIER,1N4001
D917 9A09125200 SLEEVING,OD2XID1XL5MM
D917 9A09126600 RECTIFIER,1N5392
F901,F902 9A07451800 FUSECLIP
F901,F902£ 9A09125800 FUSE,6.3A250VSLOW
F905‑F908 9A07451800 FUSECLIP
F905‑F908£ 9A09125700 FUSE,1.6A250VSLOW
IC401 9A09046500 IC,TC4052BFN
IC402‑404 9A09123800 IC,JRC4558D
IC405,406 9A08824200 IC,TC4053BFN
IC407 9A09123800 IC,JRC4558D
IC408 9A09046300 IC,M62446FP
IC409‑411 9A09123800 IC,JRC4558D
IC501‑503 9A09126800 IC,TDA7265
IC901£ 9A08825600 IC,7812
IC901,902 9A09125500 HEATSINK
IC902£ 9A09127000 IC,7912
IC903 9A09125400 HEATSINK
IC903£ 9A07463000 IC,MC7806ACT
IC905£ 9A09126900 IC,BA05T
JK105 9A09125100 RCAJACK,1PBLK
JK106 9A09124900 TOSLINKJACK,TOTX178A
JK401 9A09124700 RCAJACK,6PWHT/RED
JK402 9A09125000 RCKJACK,1PBLK
MAIN PCB ASSY
REF.NO. PARTSNO. DESCRIPTION
JK501 9A09124800 SPKJACK,10P
L501‑L503 9A07464000 RFCOIL,1UH
L505,L506 9A07464000 RFCOIL,1UH
Q401‑Q403 9A07461700 TR,2SC2878
Q404 9A07449500 TR,2SC945P
Q501‑Q503 9A07449500 TR,2SC945P
Q504,Q505 9A07449600 TR,2SA733Q/P
Q506 9A07449500 TR,2SC945P
Q901 9A07450400 TR,2SC2001L
Q905,Q907 9A07463800 TR,2SB772P/Q
Q906,Q908 9A07461700 TR,2SC2878
Q909,Q911 9A07449600 TR,2SA733Q/P
Q910,Q912 9A07449500 TR,2SC945P
Q913 9A07449600 TR,2SA733Q/P
Q914 9A07449500 TR,2SC945P
R26‑R28 9A09125200 SLEEVING,OD2XID1XL5MM
R443,R448 9A09125200 SLEEVING,OD2XID1XL5MM
R516‑R519 9A09125200 SLEEVING,OD2XID1XL5MM
R904,R908 9A09125200 SLEEVING,OD2XID1XL5MM
R922£ 9A09127500 R,33OHM1/2W5%
R925,R926 9A09125200 SLEEVING,OD2XID1XL5MM
R925,R926£ 9A09126400 R,1OHM1/2W5%
RB102 9A09124300 CONNECTOR,28PFFC
ZD401,402 9A09045000 DIODE,ZENER6.9‑7.2V0.5W
ZD403,404 9A07461800 DIODE,ZENER6.0‑6.3V0.5W
KEY PCB ASSY (GATHER)
REF.NO. PARTSNO. DESCRIPTION
9A09113400 KEYPCBASSY[J,US,C]
9A09113420 KEYPCBASSY
[HK,SG,E,K,UK,SAF,NZ,F]
KKEEYYPPCCBBAASSSSYY
9A09137700 KEYPCBASSY
9A09139500 KEYPCB
CN202 9A08310300 CONNECTOR,B4B‑PH‑K
D201‑D203 9A07449400 DIODE,1N4148
DP201 9A09138200 VFD
IC201 9A09138600 IC,PT6311
SN201 9A09138700 IRTSENSOR
TA202‑210 9A09138300 SW,TACT
VR201 9A08320700 R‑ENCODER
ZD201 9A09121800 DIODE,ZENER4.1‑4.3V0.5W
PPHHOONN EE PPCC BB AASS SS YY
9A09137800 PHONEPCBASSY
C306,C307 9A07461700 TR,2SC2878
FB302,303 9A09121900 BEADFERIT,3.5DIAX6MM
IC304 9A09139000 IC,TDA2822
JK301 9A07465300 PHONEJACK,BLK
Q308 9A07450400 TR,2SC2001L
ZD301 9A07461800 DIODE,ZENER6.0‑6.3V0.5W
LLEEDDPPCCBBAASSSSYY
9A09137900 LEDPCBASSY
D204 9A07465600 LED,RED
TA201 9A09138300 SW,TACT
